Configuring Member Links for IP Sessions over Gigabit EtherChannel

Command or Action
Step 11
initiator {dhcp | radius-proxy | static ip subscriber list
listname | unclassified ip | unclassified mac-address}
Example:
Router(config-subscriber)# initiator dhcp
Configuring Member Links for IP Sessions over Gigabit
EtherChannel
SUMMARY STEPS
1. interface GigabitEthernet slot/subslot/port
2. no ip address ip-address mask [secondary [vrf vrf-name] ]
3. carrier-delay {delay-seconds | msec milliseconds}
4. lacp port-priority priority
5. channel-group channel-group-number mode {active | passive}
DETAILED STEPS
Command or Action
Step 1 interface GigabitEthernet slot/subslot/port
Example:
Router(config)#interface GigabitEthernet0/0/1
Step 2 no ip address ip-address mask [secondary [vrf
vrf-name] ]
Example:
Router(config-if)#no ip address
Step 3 carrier-delay {delay-seconds | msec milliseconds}
Example:
Router(config-if)# carrier-delay msec 50
Step 4 lacp port-priority priority
Example:
Router(config-if)#lacp port-priority 4000
Intelligent Wireless Access Gateway Configuration Guide
28
Purpose
Enables the Cisco ISG to create an IP subscriber session
upon receipt of a specified type of packet.
Purpose
Enters the interface configuration mode for Gigabit Ethernet
interface.
Removes an IP address from an interface.
Sets the carrier delay on a serial interface. To achieve faster
switchover from active to standby member link, the carrier delay
value can be set to 0 ms.
Sets the LACP priority for a physical interface. IPoGEC currently
supports 1:1 model, that is one active member link and one
standby member link, which only requires choosing two different
values for priority field to make sure one interface is active while
the other is standby. The value set for the priority field shall
match the value configured on the switch.
