PARTS LIST
No
Description
1
Cable
2
Strain Relief
3
Cable Pressboard
4
Screw ST 4x14
5
Capacitance 0.33 μF
6
Carbon Brush
7
Carbon Brush Holder
8
Motor Housing Left
9
ON/OFF Switch
10
Handle
11
Nut M6
12
Motor Housing Right
13
Screw ST 4x16
14
Axis
15
Label
16
Nut M5
17
Stator
18
Bearing 606Z
19
Rotor
20
Bearing 608Z
21
Small Wheel
22
Bearing 607Z
23
Drive Belt
24
Retainer Ring 10
25
Big Wheel
26
Pin 3x5
27
Spindle
28
Press Plate
29
Grinding Disc Ø100
30
Gasket 8
31
Nut M8
32
Bolt M5x16
33
Protective Cover
34
Spring
35
Gasket 5
36
Bolt M5x20
37
Transparent Cover
38
Adjusting Screw 1
Part number
No
Description
KPECSS1001
39
Nut M6
KPECSS1002
40
Nut M6x12
KPECSS1003
41
Chain Guide
KPECSS1004
42
Bolt M5x35
KPECSS1005
43
Left Chain Holder
KPECSS1006
44
Right Chain Holder
KPECSS1007
45
Bolt M5x10
KPECSS1008
46
Adjustment Wedge
KPECSS1009
47
Nut M5
KPECSS1010
48
Spring 1
KPECSS1011
49
Guide Board
KPECSS1012
50
Bolt M8x50
KPECSS1013
51
Bearing 6000Z
KPECSS1014
52
Spring 2
KPECSS1015
53
Gasket 6
KPECSS1016
54
Bolt M6x16
KPECSS1017
55
Right Pivot Clamp
KPECSS1018
56
Left Pivot Clamp
KPECSS1019
57
Pin M6x12
KPECSS1020
58
Bracket
KPECSS1021
59
Adjusting Screw 2
KPECSS1022
60
Spring 3
KPECSS1023
61
Nut M8
KPECSS1024
62
Locknut
KPECSS1025
63
Swivel Plate
KPECSS1026
64
Base
KPECSS1027
65
Spring
KPECSS1028
66
Steel Ball SØ5
KPECSS1029
67
Bolt M4x10
KPECSS1030
68
Splint
KPECSS1031
69
Chain Holder Assy
KPECSS1032
70
Spring
KPECSS1033
71
Press Board
KPECSS1034
72
Bolt M8x80
KPECSS1035
73
Wrench 4x22x60
KPECSS1036
74
Wrench 5x22x65
KPECSS1037
75
Jaw Wrench
KPECSS1038
76
Socket Wrench
13
Part number
KPECSS1039
KPECSS1040
KPECSS1041
KPECSS1042
KPECSS1043
KPECSS1044
KPECSS1045
KPECSS1046
KPECSS1047
KPECSS1048
KPECSS1049
KPECSS1050
KPECSS1051
KPECSS1052
KPECSS1053
KPECSS1054
KPECSS1055
KPECSS1056
KPECSS1057
KPECSS1058
KPECSS1059
KPECSS1060
KPECSS1061
KPECSS1062
KPECSS1063
KPECSS1064
KPECSS1065
KPECSS1066
KPECSS1067
KPECSS1068
KPECSS1069
KPECSS1070
KPECSS1071
KPECSS1072
KPECSS1073
KPECSS1074
KPECSS1075
KPECSS1076
