- Page 1 CHAINSAW SHARPENER MODEL: ECSS-1 Part No: 3402075 ASSEMBLY & INSTRUCTION MANUAL LS0409...
-
Page 2: Introduction
GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. -
Page 3: Table Of Contents
CONTENTS INTRODUCTION ....................2 GUARANTEE ....................2 ENVIRONMENTAL PROTECTION ..............2 PARTS & SERVICE ................... 2 SAFETY PRECAUTIONS ................... 3 OPERATING HINTS ..................4 ELECTRICAL CONNECTIONS ................ 5 PARTS IDENTIFICATION .................. 6 ASSEMBLY ....................... 7 OPERATING ....................8 MAINTENANCE AND CLEANING ..............10 SPECIFICATION .................... -
Page 4: Operating Hints
OPERATING HINTS • Before you sharpen the chainsaw chain check it for damages, such as: bent or abraded chain links. broken cutting teeth, loose rivets or broken rivet heads. If any damage is found, replace the entire chain. • A sharp chainsaw produces wood Fig 1 chips and pulls itself into the timber being cut. -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. -
Page 6: Parts Identification
PARTS IDENTIFICATION... -
Page 7: Assembly
ASSEMBLY The chain saw sharpener is supplied only partly assembled. 1. Remove the bolts from both pivot clamps as shown in Fig 4. 2. Insert the axle into the body of the chainsaw sharpener. Fig 5. 3. Place the chainsaw sharpener on the base plate. -
Page 8: Operating
OPERATING WHEN SHARPENING, ALWAYS WEAR SAFETY GOGGLES. FITTING THE CHAIN TO THE Fig 8 SHARPENER 1. Lift up the adjustment wedge (G) and unscrew the fastening screw (F), see Fig 8. 2. Place the chainsaw chain on the chain holder assembly (J). •... - Page 9 SWITCHING ON/OFF Fig 10 6. To switch on, set the ON/OFF switch to the ( I ) position. see Fig 7. To switch off, set the ON/OFF switch to the ( O ) position. see Fig 10 SHARPENING THE CHAIN 8.
-
Page 10: Maintenance And Cleaning
• Replacement grinding disc speed must meet or exceed the RPM rating of the unit. Note: Replacement discs are available from your Clarke dealer part number (3402076) 4. Tighten the nut and mount the protective cover (D) on the unit. -
Page 11: Specification
SPECIFICATION Nominal Voltage ........230 V Frequency ..........50 Hz Nominal Power ......... 130 W No Load Speed ........3000 rpm Disc Diameter ........... Ø 100 mm Weight ............2.5 kg Protection Class ........II Sound Pressure Level ....... 85.8 dB(A) Sound Power Level ........ -
Page 12: Parts Diagram
PARTS DIAGRAM... -
Page 13: Parts List
PARTS LIST Description Part number Description Part number Cable KPECSS1001 Nut M6 KPECSS1039 Strain Relief KPECSS1002 Nut M6x12 KPECSS1040 Cable Pressboard KPECSS1003 Chain Guide KPECSS1041 Screw ST 4x14 KPECSS1004 Bolt M5x35 KPECSS1042 Capacitance 0.33 μF KPECSS1005 Left Chain Holder KPECSS1043 Carbon Brush KPECSS1006 Right Chain Holder... -
Page 14: Declaration Of Conformity
DECLARATION OF CONFORMITY... - Page 15 NOTES...
