MAINTENANCE AND CLEANING

• Use a dry paint-brush to clean the unit and remove grinding
residues.
• Do not clean the unit with aggressive detergents or chemicals.
• The unit does not require any lubrication.
CHANGING THE GRINDING DISC
BEFORE CARRYING OUT ANY WORK ON THE CHAIN SAW SHARPENER
DISCONNECT THE PLUG FROM MAINS SUPPLY.
1. Unscrew the bolts indicated
using the hexagonal key
supplied and remove the
protective cover (D).
2. Use the wrench supplied to lock
the spindle and then loosen the
nut with the socket wrench.
3. Place the new grinding disc over
the spindle.
• Only use grinding discs with a
diameter of 100 mm.
• Replacement grinding disc
speed must meet or exceed
the RPM rating of the unit.
Note: Replacement discs are available from your Clarke dealer part
number (3402076)
4. Tighten the nut and mount the protective cover (D) on the unit.
See Fig 14.
Fig 14
Fig 15
