- Page 1 CORDLESS IMPACT WRENCH MODEL NO: CIR184LiP PART NO: 4500619 OPERATING & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS DL1123...
- Page 2 INTRODUCTION Thank you for purchasing this CLARKE Impact Wrench. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
-
Page 3: Product Overview
PRODUCT OVERVIEW The CIR184LIP is a professional, cordless impact wrench which is rechargeable using the mains power adaptor. The key design features are shown above. Upon receipt, check the components against the following list. Any damage or deficiency should be reported to your CLARKE dealer immediately. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS WORK ENVIRONMENT 1. Keep the work area clean and tidy and free from trip hazards. 2. DO NOT wear loose clothing or jewellery. Tie long hair out of the way. 3. If wearing gloves, make sure that there is no frayed material that could catch in rotating parts. -
Page 5: Impact Wrench Safety Instructions
14. NEVER attempt any repairs yourself. If you have a problem with this product contact your local CLARKE dealer. 15. ALWAYS use an approved cable extension suitable for the power rating of the battery charger (see specifications), the conductor size should also be at least the same size or larger than that on the charger. -
Page 6: Safety Symbols
explode when exposed to fire. DO NOT attempt to open, disassemble, modify or service a battery pack. 5. Handle batteries so as to avoid damage, fire, corrosion or personal injury. 6. NEVER crush, puncture, short external contacts or dispose of in fire or water. 7. -
Page 7: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. The battery charger for this product is provided with a standard 3 amp, 230 volt (50Hz), BS 1363 plug, for connection to a standard, domestic electrical supply. -
Page 8: Battery Charging
BATTERY CHARGING The battery will have been shipped in a low charge state and will require charging before use. 1. Press the battery release clip on the front of the battery pack and slide the battery pack from the impact wrench. 2. - Page 9 5°C (41°F) and 40°C (104°F). Wait for the battery to cool down. Red Light The voltage of the battery Contact CLARKE service Flashing is too low. Circuit inside department for new battery. battery is open CHECKING THE BATTERY STATUS...
-
Page 10: Operation
OPERATION CAUTION: MAKE SURE THAT THE IMPACT WRENCH IS LOCKED USING THE SELECTOR BAR BEFORE ATTACHING OR REMOVING A SOCKET. ALWAYS TAKE CARE TO USE THE CORRECT SIZE SOCKET FOR BOLTS AND NUTS. AN INCORRECT SOCKET WILL CAUSE DAMAGE TO THE BOLT OR NUT. FITTING A SOCKET 1. -
Page 11: Speed Selection
SPEED SELECTION 1. Three running speeds are available by clicking the speed selection button (5) shown, a green light will show which speed has been selected. The speeds are as follows: • 1: 1000 RPM • 2: 1500 PRM • 3: 2100 RPM •... -
Page 12: Troubleshooting
This can be fitted to either side of the main housing, adjacent to the battery and is retained by a single screw. TROUBLESHOOTING If the following does not solve your problem contact the CLARKE service dept. PROBLEM CAUSE SOLUTION Unit will not... -
Page 13: Maintenance
Keep the unit clean by wiping with a dry cloth. DO NOT use solvents as a cleaning agent. Your CLARKE impact wrench has been designed to give long and trouble free service. If, however, having followed the instructions in this booklet carefully, you encounter problems, take the unit to your local CLARKE dealer. -
Page 14: Battery Disposal
ACCESSORIES A wide range of impact wrench accessories is available from your nearest CLARKE dealer, for further information, contact your nearest dealer, or telephone CLARKE International Sales department on 01992 565300. Suitable impact wrench compatible socket sets include the following:... -
Page 15: Specifications
1.5 m/s Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 16: Component Parts List
COMPONENT PARTS LIST Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 17 Description No Description Aluminum Shield Gearing Screw Gearing Pins Gasket Gear Pin Gasket Aluminum Head Bearing Anvil Collar T Type Anvil Washer Motor T Type Bearing Back Cover Steel Ball Activation Switch Impact Block PCB Board Steel ball Light Cover Impact Block Washer Battery Indicator Forward/Reverse Switch...
- Page 18 DECLARATION OF CONFORMITY - UKCA Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 19: Declaration Of Conformity (Ce)
DECLARATION OF CONFORMITY - CE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
