ETH100
4 Laser options
The ETH100 card is available in the following versions:
ETH100-13T -7.5dBm
ETH100-13T 0 dBm
ETH100-15T 0 dBm
ETH100-C1470
ETH100-C1490
ETH100-C1510
ETH100-C1530
ETH100-C1550
ETH100-C1570
ETH100-C1590
ETH100-C1610
1310± 40nm -7.5 dBm F-P laser
1310± 40nm 0 dBm F-P laser
1550± 40nm 0 dBm DFB laser
CWDM (DFB lasers)
1470± 6nm 0dBm
1490± 6nm 0dBm
1510± 6nm 0dBm
1530± 6nm 0dBm
1550± 6nm 0dBm
1570± 6nm 0dBm
1590± 6nm 0dBm
1610± 6nm 0dBm
ETH100-C1270
1270± 6nm 0dBm
ETH100-C1290
1290± 6nm 0dBm
1310± 6nm 0dBm
ETH100-C1310
ETH100-C1330
1330± 6nm 0dBm
ETH100-C1350
1350± 6nm 0dBm
ETH100-C1370
1370± 6nm 0dBm
ETH100-C1390
1390± 6nm 0dBm
ETH100-C1410
1410± 6nm 0dBm
network-electronics.com | 7
Rev. 7
