ETH100
1 Product versions
There are two different hardware versions of the ETH-100 card which are referred to as
"Version 1" and "Version 2" in this manual. The figures below show how to distinguish the
two versions from each other. The only difference is the DIP switch row, which is
implemented on Version 2, this described in chapter 7.3.
ETH-100 Version 1
ETH-100 Version 2
(with DIP switches)
network-electronics.com | 4
Rev. 7
