Technical Specifications

BP15DSP Loudspeaker
System Type ......................................2-Way Powered Speaker
Transducer Low ................................15" Neodymium Woofer, 2.5" Voice Coil
Transducer High................................1" Compression Driver, 1.75" Voice Coil
Horn Coverage (H x V
˚
Frequency Response ......................45 Hz to 20 kHz with FLAT
Crossover Frequency ......................2.2 kHz-DSP Processor 12 dB/oct
Max. SPL (1m)....................................124 dB Maximum
Power System ..................................Bi-Amp (Low: Class D 300W High; Class AB 50W), RMS 350W
Connector ..........................................LINE/MIC Input with Combo on (XLR/ 1/4") Connector
External Controls ..............................Volume Control, LINE/MIC Switch, Low Frequency Switch,
LED ....................................................Power (Green), Signal/Clip (Green/Red)
Low Frequency Presets ..................CUT - FLAT - BOOST
Electronic Protections......................Thermal / Overload / Digital Limiter / Compressor
Power Supply ....................................110-120V~50/60 Hz or 220-240V~50/60 Hz Switchable (550W)
Enclosure Construction ..................Plastic Cabinet, Trapezoidal & Monitor Shape, Metal Grille,
Mounting ............................................36mm standard pole-mount, M10 6PCS Flying Points
Dimensions (H x W x D) ..................26-1/8" x 15-1/2" x 15-7/8" (664mm x 396mm x 402mm)
Net Weight ........................................40.5 lbs. (18.4kg)
BP12DSP Loudspeaker
System Type ......................................2-Way Powered Speaker
Transducer Low ................................12" Neodymium Woofer, 2.5" Voice Call
Transducer High................................1" Compression Driver, 1.75" Voice Call
Horn Coverage (H x V
˚
Frequency Response ......................50 Hz to 20 kHz with FLAT
Crossover Frequency ......................2.4 kHz-DSP Processor 12 dB/oct
Max. SPL (1m)....................................123 dB Maximum
Power System ..................................Bi-Amp (Low: Class D 300W High; Class AB 50W), RMS 350W
Connector ..........................................LINE/MIC Input with Combo on (XLR/ 1/4") Connector
External Controls ..............................Volume Control, LINE/MIC Switch, Low Frequency Switch,
LED ....................................................Power (Green), Signal/Clip (Green/Red)
Low Frequency Presets ..................CUT - FLAT - BOOST
Electronic Protections......................Thermal / Overload / Digital Limiter / Compressor
Power Supply ....................................110-120V~50/60 Hz or 220-240V~50/60 Hz Switchable (550W)
Enclosure Construction ..................Plastic Cabinet, Trapezoidal & Monitor Shape, Metal Grille,
Mounting ............................................36mm standard pole-mount, M10 6PCS Flying Points
Dimensions (H x W x D) ..................26-1/8" x 15-1/2" x 14-1/4" (664mm x 396mm x 362mm)
Net Weight ........................................38.5 lbs. (17.5kg)
) ..................90˚H x 45˚V
˚
Power, Pin 1 Lift Switch
Rubber Feet, 2 Handles (both sides)
) ..................90˚H x 45˚ V
˚
Power, Pin 1 Lift Switch
Rubber Feet, 2 Handles (both sides)
8
