- Page 1 TruVision Analog PTZ Camera Configuration Manual P/N 1072658A-EN • REV 1.0 • ISS 11OCT13...
- Page 2 Copyright © 2013 UTC Fire & Security Americas Corporation, Inc. Interlogix is part of UTC Climate Controls & Security, a unit of United Technologies Corporation. All rights reserved. Trademarks and The TruVision and Interlogix names and logos are trademarks of patents United Technologies.
-
Page 3: Table Of Contents
Noise reduction 17 HLC (high light compensation) 17 Privacy masking 17 PTZ control parameters 19 Proportional panning 19 Dwell time and actions 20 Freeze image 20 Limit stops 20 Presets 21 Preset tours 23 TruVision Analog PTZ Camera Configuration Manual... - Page 4 Alarm inputs and linked actions 31 Alarm parameters 32 Auxiliary alarm output 32 Password 33 Tracking settings 34 Restore default camera settings 35 Reboot the camera 35 KTD-405 and DVR control feature list 36 TruVision Analog PTZ Camera Configuration Manual...
- Page 5 TruVision Analog PTZ Camera Configuration Manual...
-
Page 7: Introduction
Before programming, ensure that the PTZ camera has the power, control, video cables correctly connected. For information on installing the PTZ camera, please refer to the “Truvision Analog PTZ camera Installation Manual” supplied with the PTZ camera. The PTZ camera is programmed through the on-screen (OSD) menus. You can access to the OSD menu of a PTZ camera by using a control device, such as a keypad, DVRs, etc. -
Page 8: System-Defined Presets
Preset Tour 7 Enable limit stops Preset Tour 8 Note: Please ensure that the baud rate, data bit, and address have been configured for the camera are the same as those in the control device. TruVision Analog PTZ Camera Configuration Manual... -
Page 9: Programming
To move the cursor and select an item: 1. Move the cursor up/down: In live view mode, click the UP/DOWN buttons or the FOCUS + FOCUS- buttons in the PTZ control panel to move the cursor up and down. TruVision Analog PTZ Camera Configuration Manual... -
Page 10: View System Information
Main Menu >System Information. The System Information menu appears. Change system settings System information settings You can check and edit the system settings on address, communication, protocol, time, etc. in the System Information Settings menu. TruVision Analog PTZ Camera Configuration Manual... - Page 11 Note: When there is more than one page to a submenu, click the left/right buttons in the PTZ control panel of the DVR to enter the next page and return to the previous page of the submenu. Figure 2: System information settings TruVision Analog PTZ Camera Configuration Manual...
-
Page 12: Camera Address Settings
Use the direction buttons to move the cursor to and click IRIS+ to enter. 3. Click the left/right buttons to move the cursor on the item (year/month/day or hour/minute/second) that you want to change. TruVision Analog PTZ Camera Configuration Manual... -
Page 13: Zero Point (Initial Position) Setting
You can enable or disable the on-screen display for the information of zoom, PTZ movements, alarms, time, presets, zone, address, error rate, and fan and heat, etc. See Figure 3 below. Figure 3: Display settings menu TruVision Analog PTZ Camera Configuration Manual... -
Page 14: Fan Control
Set 485Check to On or Auto for automatic RS-485 configuration diagnosis. If the configuration is incorrect, an alert will be received by users; if you set the value as AUTO, it will finish the diagnosis if no error in the configuration is detected TruVision Analog PTZ Camera Configuration Manual... -
Page 15: Camera Settings
Figure 4: Camera menu To access the Camera menu: 1. Go to MAIN MENU > SYSTEM SETTINGS > CAMERA. Focus To set the camera focus: 1. Go to MAIN MENU > SYSTEM SETTINGS > CAMERA. TruVision Analog PTZ Camera Configuration Manual... -
Page 16: Zoom Limit
3. Click the up/down buttons to select the speed: High (default), Middle, and Low. 4. Click IRIS+ to confirm. Day/Night mode There are two parameters available for day/night mode configuration. 1. IR CUT FILTER. It can be set as Auto, Day or Night. TruVision Analog PTZ Camera Configuration Manual... -
Page 17: Blc And Wdr Functions
This is the default mode. • Iris: This is the iris-priority mode. Define the iris value depending on the lighting conditions. • Shutter: This is the shutter-priority mode. Define the shutter speed depending on the lighting conditions. TruVision Analog PTZ Camera Configuration Manual... -
Page 18: Iris Value
Note: In CUSTOM. mode you need to define the value of RED and BLUE. Image flip If you enable the IMAGE FLIP function, the image is flipped diagonally along its central axis, seen as a mirror reflection of the image. TruVision Analog PTZ Camera Configuration Manual... -
Page 19: Focus Limit
You can set the privacy mask to cover certain areas from live viewing and recording. The masked areas can move with the pan/tilt movements and their size can vary automatically when the lens zooms. TruVision Analog PTZ Camera Configuration Manual... - Page 20 Click IRIS+ button to save the settings and return to the previous menu. The mask becomes grey. TruVision Analog PTZ Camera Configuration Manual...
-
Page 21: Ptz Control Parameters
(zoom out). The panning and tilting speeds are slower in telephoto state compared to the wide zoom state. You can set PROPORTIONAL PAN to ON or OFF to enable/disable the function. Note: This function is automatically enabled when configuring shadow tours. TruVision Analog PTZ Camera Configuration Manual... -
Page 22: Dwell Time And Actions
Click the direction buttons in the PTZ panel to configure the left limit stop. Click IRIS+ to confirm. Follow the prompts to configure the right, up and down limit stops on the menu. Note: The new limit stops will overwrite the existed ones by default. TruVision Analog PTZ Camera Configuration Manual... -
Page 23: Presets
3. Select the preset number. To edit a preset label: 1. Go to MAIN MENU > SYSTEM SETTINGS > PRESETS 2. Move the cursor to EDIT LABLE and click IRIS+ to enter the edit mode. TruVision Analog PTZ Camera Configuration Manual... - Page 24 3. Use the direction buttons to move the PTZ camera to the desired scene/position. Press IRIS+ to confirm the settings and return to the previous menu, or press IRIS- to cancel. Note: The preset position settings are restricted by limit stops, if defined. TruVision Analog PTZ Camera Configuration Manual...
-
Page 25: Preset Tours
3. Click the up and down buttons to select the number of the preset tour to be configured. 4. Click IRIS+ again to confirm and exit edit mode of this column. Note: You can configure up to 8 Preset Tours. TruVision Analog PTZ Camera Configuration Manual... - Page 26 5. Repeat steps 3 and 4 to define other presets for the selected preset tour. Press IRIS+ to save the current settings or press IRIS- to cancel and return to the previous menu. Table 3: Preset tour speeds Level Speed(°/s) Level Speed(°/s) Level Speed(°/s) TruVision Analog PTZ Camera Configuration Manual...
-
Page 27: Shadow Tours
A shadow tour is a memorized, repeatable series of panning, tilting, zooming, and preset movements that can be recalled by a command or automatically performed by a configured function (alarm, park, time task, and power-up). Figure 9: Shadow tour menu TruVision Analog PTZ Camera Configuration Manual... - Page 28 • The panning/tilting movements and the lens operations cannot be memorized simultaneously. To preview a shadow tour: 1. Go to MAIN MENU > SYSTEM SETTINGS > SHADOW TOUR. 2. Move the cursor to PREVIEW SHADOW TOUR. TruVision Analog PTZ Camera Configuration Manual...
-
Page 29: Schedules And Tasks
IRIS+ to enter edit mode 3. Click the up and down buttons to select the task number to be configured. 4. Click IRIS+ again to confirm and exit edit mode of this column. TruVision Analog PTZ Camera Configuration Manual... - Page 30 Note: The weekday can be set to be from Monday to Sunday, or Whole Week. 4. Click the up and down buttons to select the specific day and time. 5. Click IRIS+ to confirm and exit. TruVision Analog PTZ Camera Configuration Manual...
-
Page 31: Zones
3. Click the direction buttons to set the left limit stop. 4. Follow the prompts on screen to set the right limit, up limit, and down limit. 5. Click IRIS+ to save the settings and exit. TruVision Analog PTZ Camera Configuration Manual... -
Page 32: Clear Ptz Control Settings
To clear PTZ settings: 1. Go to MAIN MENU > SYSTEM SETTINGS > CLEAR SETTINGS. 2. Click IRIS+ on each submenu to be deleted. For example, CLEAR SHADOW TOURS. 3. Click IRIS+ again to confirm and exit. TruVision Analog PTZ Camera Configuration Manual... -
Page 33: Alarms
To configure the alarm linkage action: You can specify the linked action when an alarm occurs. On the TRIGGER ACTION submenu, set the alarm action as preset 1-8, shadow tour 1-4, preset tour 1-8, panning TruVision Analog PTZ Camera Configuration Manual... -
Page 34: Alarm Parameters
PTZ positions, focus and iris value. Auxiliary alarm output An auxiliary output is a configurable alarm output interface on the PTZ camera back box which can connect and trigger another alarm device to operate. See TruVision Analog PTZ Camera Configuration Manual... -
Page 35: Password
After you set and enable the password, you need to enter the password each time you call preset 95 to enter the menu. See Figure 15 on page 34. TruVision Analog PTZ Camera Configuration Manual... -
Page 36: Tracking Settings
PASSWORD ENABLE submenu and switch the status to and click IRIS+ to save. Tracking settings You can enable tracking to track the person in the image. See Figure 16 below. Figure 16: Tracking menu TruVision Analog PTZ Camera Configuration Manual... -
Page 37: Restore Default Camera Settings
2. Click IRIS+ to restore the camera settings to the default value or click IRIS- to exit. Reboot the camera Enter MAIN MENU > REBOOT SYSTEM and click IRIS+ to reboot the PTZ camera remotely. TruVision Analog PTZ Camera Configuration Manual... -
Page 38: Ktd-405 And Dvr Control Feature List
KTD-405 and DVR control feature list Features KTD-405 Joystick up down left right Joystick up-left up-right down-left down- right Joystick ZOOM+/ZOOM- ZOOM+/ZOOM- FOCUS+/FOCUS- IRIS+/IRIS- Auto focus Calling presets: find Store presets: store Store shadow tour: None Calling shadow tour: tour Notes: 1.
