Figure 6: SDHC card location in the dome cameras

Mounting the dome cameras on a ceiling

Mount the dome cameras on a ceiling. They are not recommended for mounting
on a wall.
Note: If required, cables can be feed through the sides of the dome housing by
removing the tabs (1) using a pliers (see Figure 7 below).
Figure 7: Creating cable access points in the dome housing (optional)
To mount the dome camera on a ceiling:
1. Place the mounting plate (supplied) on the ceiling.
2. Securely fasten the mounting plate to the ceiling surface with the supplied
screws.
3. In the middle of the mounting plate make a hole in the ceiling to access the
cabling.
TruVision IP Dome Open-Standards User Manual
SDHC card slot
