LevelOne FSW-1640TX User Manual page 27

[ Chip 00 : Disable Trunking ]
Trunk\Port 09 10
----------------------------------------------------------------------
--------
T_G[01]
T_G[02]
T_G[03]
T_G[04]
[ Chip 01 : Disable Trunking ]
Trunk\Port 05 06
----------------------------------------------------------------------
--------
T_G[05]
T_G[06]
T_G[07]
T_G[08]
[ Chip 02 : Disable Trunking ]
Trunk\Port 01 02
----------------------------------------------------------------------
--------
T_G[09]
T_G[10]
T_G[11]
T_G[12]
Select Chip (0~2):
Select Chip: select chip number. It means the specific chip will have such
ability of port trunking after setting Trunk group and Forwarding table.
After you select one chip, you can press "E" or "D" to Enable or Disable the
Trunking function to the selected chip.
[ Chip 00 : Disable Trunking ]
Trunk\Port 09 10
----------------------------------------------------------------------
--------
T_G[01]
T_G[02]
T_G[03]
T_G[04]
[ Chip 01 : Disable Trunking ]
Trunk\Port 05 06
----------------------------------------------------------------------
--------
T_G[05]
T_G[06]
T_G[07]
T_G[08]
[ Chip 02 : Disable Trunking ]
Trunk\Port 01 02
----------------------------------------------------------------------
--------
T_G[09]
T_G[10]
T_G[11]
T_G[12]
Select Chip (0~2): (E)nable/(D)isable Trunking
For the selected chip, you can now set up the Trunking port.
T: Setting trunk group. Per chip provide 4 trunk groups and there are at least
LevelOne FSW-2440TX
24-Port Smart Switch
11 12 21
07 08 17
03 04 13
LevelOne FSW-2440TX
24-Port Smart Switch
11 12 21
07 08 17
03 04 13
27
22 23 24
18 19 20
14 15 16
22 23 24
18 19 20
14 15 16
