Port 01 02
12
----------------------------------------------------------------------
---------
OFF OFF
OFF
Port 13 14
24
----------------------------------------------------------------------
---------
OFF OFF
OFF
No Capture Port select!
Ingress Filter : All frames
MAC : 00-00-00-00-00-00
00-00-00-00-00-00
Divider : 00000
[P]: set Port mirror status, [R]: Reset all mirror Configure
[I]: Ingress rule Configure, [E]: Egress rule Configure
[ ]

6.4.1 P: set Port mirror status

P: set port mirror status to be the capture port or mirror ingress, egress or
both ingress and egress frames on the selected port.
After select one port, you have 5 settings to the selected port.
C: set the Capture port.
B: mirror both Ingress and Egress frames of the selected port.
O: set to OFF.
I: only mirror ingress frames.
E: only mirror egress frames.
For example: Set port#01 as capture port and mirror both ingress and egress
frames of port#02.
Choose port#01 as Mirror Capture Port.
LevelOne FSW-2440TX
24-Port Smart Switch
====================
03 04 05 06
OFF OFF OFF OFF
15 16 17 18
OFF OFF OFF OFF
Egress Filter : All frames
19
07 08 09 10
OFF OFF OFF OFF
19 20 21 22
OFF OFF OFF OFF
MAC :
Divider : 00000
[ESC]:Exit
11
OFF
23
OFF
