Ingress/Egress ports.
M: enter MAC Address
Press 'M' to setup the MAC Address.
V: set Divider
Press 'V' to set Ingress/Egress mirror divider. The value indicates
receive/transmit frames that have passed the device and divided by the value
only one in n frames.
Port 01 02
12
----------------------------------------------------------------------
---------
CAP OFF
OFF
Port 13 14
24
----------------------------------------------------------------------
---------
OFF OFF
OFF
Ingress Filter : All frames
MAC : 00-00-00-00-00-00
00-00-00-00-00-00
Divider : 00000
[P]: set Port mirror status, [R]: Reset all mirror Configure
[I]: Ingress rule Configure, [E]: Egress rule Configure
[I] ---> [P]: mirror all port's frames
[D]: mirror Dest. MAC Address
[S]: mirror Source MAC Address
[M]: enter MAC Address
[V]: set Divider
[ESC]: Exit
[ ]
NOTE:
1. Only one port can be chosen as capture port at the same time.
2. Mirror multi-ports is possible but can create congestion at the mirror
capture port.
3. The Ingress/Egress mirror divider indicate that all frames pass to/through
the device will be captured to the monitor port in n frames, the n value will
display in decimal and the range is from 0 to 1023.

6.5 VLAN Function

Every time select this submenu, we have to check whether to reset the
original VLAN Configure. Select (Y)es to reset VLAN group. It means that
system will clear all VLAN group after select (Y)es.
03 04 05 06
OFF OFF OFF OFF
15 16 17 18
OFF OFF OFF OFF
Egress Filter : All frames
23
07 08 09 10
OFF OFF OFF OFF
19 20 21 22
OFF OFF OFF OFF
MAC :
Divider : 00000
[ESC]:Exit
11
OFF
23
OFF
