Deleting or Editing a VLAN

When a VLAN is selected, you can delete it or edit its
properties.
1 Click the VLANs tab.
2 In the VLANs window, select a VLAN.
To delete the selected VLAN, click Delete VLAN.
To edit the VLAN ID for the selected VLAN, click Edit VLAN.

Displaying NIC Properties

1 Click the Load Balance/RSL tab.
2 In the Load Balance/RSL window, select a NIC.
3 Click Properties.
The NIC Properties window appears, showing the
properties of the selected NIC.

Displaying Group Properties

1 Click the Load Balance/RSL tab.
2 In the Load Balance/RSL window, select a group in
the Load Balancing/RSL Groups list box.
3 Click Properties.
The Group Properties window appears, showing the
properties of the selected group.

Specifying Failover from Gigabit to 10/100 PCI

You can specify failover from a 3Com Etherlink Server
1000 PCI NIC to a 3Com EtherLink Server 10/100 PCI NIC.
To ensure optimal performance, this type of failover
requires that you disable load balancing for the group.
1 Create a group.
See
2 Add 3Com server NICs to the group.
Add at least one 3Com Gigabit Etherlink Server NIC and at
least one 3Com EtherLink Server 10/100 PCI NIC to the
group. Designate the Gigabit Etherlink Server NIC as the
primary NIC.
See
Creating a Group.
Adding NICs to a Group on page
Configuring Groups and VLANs
36.
41
