3Com EtherLink 3C980C-TXM User Manual page 27

15 seconds, the installation routine does not install
DynamicAccess server features.
If you click No to the installation prompt, you can install
DynamicAccess server features later by running the
Daserver program, which is located in the Windows System
32 directory (for example, in win2k\system32).
14 Respond to the prompt to close all programs.
In the Windows NT Network window, click Close.
Bindings messages appear.
If your network environment uses the TCP/IP
communications protocol, the Microsoft TCP/IP Properties
dialog box appears. Enter the information needed to define
an IP address. Continue after you have defined the TCP/IP
settings.
When DynamicAccess server features are installed, NICs
bind to the DynamicAccess protocol and real protocols
bind to the DynamicAccess Miniport. Do not modify
these bindings.
15 Remove the 3Com EtherLink Server CD from the
CD-ROM drive.
16 Restart the computer.
Table 1 SHD Parameters (Windows)
Field
Self Check Level
Sampling
Window
Range of Values
(Defaults in Bold)
Off, Basic, Enhanced
0–65536 packets
0 disables sampling.
1024
Installing in Windows NT
Description
Basic level checking monitors Tx/Rx
errors (see Sampling
beat, and NIC hardware. Enhanced
level adds maintenance of valid data
structures and uses more CPU cycles.
Basic level checking is forced when RSL
is enabled. Off disables SHD.
This option specifies the number of Tx/Rx
packets to be sampled for carrier lost,
late collisions, jabbers, CRC, overruns,
underruns, and bus contention errors.
Setting the Sampling Window to 0
effectively disables all checking.
27
Window), link
