Panel Descriptions - Gefen EXT-HDMI1.3-2-3GSDIS User Manual

1 Infrared Eye
This receiver will receive commands from the included remote control. For
proper operation, line of sight must be maintained between this receiver and the
I/R remote control..
2 3G-SDI Indicator LED
This indicator will become active when the output video stream is a 3G-SDI
signal.
3 Power Indicator LED
This indicator will become active when power is being supplied to the unit via the
included 5V DC power adapter.
4 RS-232 Control Port
This interface was designed to accept commands from an external control
system. This port will allow switching commands as confi guration operations
5 5V Locking Power Receptacle
This input will accept power via the included locking 5V DC power supply.
Connect the power supply between this input and an open wall power socket.
6 USB Input Port
This port is used to update fi rmware. For current fi rmware releases, please see
the download section at www.gefen.com.
7 Genlock Ref Signal Input
Connect Genlock reference signal here. This is designed to connect an external
clock (e.g. house clock) to the unit
8 Coax Digital Audio Output
Connect coaxial digital audio output to this port.
9 HDMI Input
This input will accept a single HDMI type A male cable. For acceptable input
formats see page 11.
10 3G-SDI Output
These outputs send converted SD/HD/3G-SDI audio/video to a single SD/
HD/3G-SDI device using a user supplied SDI cable. Converted HDMI signals
will be output through these SDI ports. For a full description of the supported A/V
formats on this output please page 12.

PANEL DESCRIPTIONS

5
