READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE HDMI 1.3 TO 3GSDI SCALER
• Upon power up, the HDMI 1.3 to 3GSDI Scaler will automatically detect the
input format of the input. The unit is controlled using the included remote.
• The following are the buttons for the RMT-8HDS-IR:
- UP (Navigates cursor up)
- LEFT (Navigates cursor left)
- ENTER (Accept Operation / Return to Menu)
- RIGHT (Navigates cursor right)
- DOWN (Navigates cursor down)
- MENU (Show / Hide Onscreen Display)
- OUTPUT (Change Output Format)
- SOURCE (Non operational)
• To bring up the on-screen menu, press the MENU button. Navigation is
done using Buttons up, left, right, and down; Push the ENTER button to ac-
cept the cursor focus.
• Pressing the Output button cycles through the following output modes: 480i
- 576i - 720p - 1080i
• Other functions and output modes can be accessed through the onscreen
menu. To Restore I/O settings, simply recycle power on the Scaler
*Note: Both DIP switches under the remote battery cover must initially be in the
OFF position to communicate with the Scaler.
