Summary of Contents for Gefen EXT-HOMETS
-
Page 1: Home Theater
Home Theater Scaler U S E R M A N U A L www.gefen.com... - Page 2 Chatsworth, CA 91311 www.gefen.com support@gefen.com Gefen Inc. reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. The Home Theater Scaler is a trademark of Gefen Inc. © 2007 Gefen Inc., All Rights Reserved...
-
Page 3: Table Of Contents
Features Panel Layout Operation Controls and Functions Operation Controls and Functions Operation Controls and Functions / Color Settings Output Settings / OSD Adjustment / Information Using the Home Theater Scaler RMT-SR-IR Installation Pin Configuration Specifications Terminology Warranty TABLE OF CONTENTS... -
Page 4: Introduction / Operation Notes
The Home Theater Scaler will embed the digital audio into the HDMI output as well as the digital audio outs. The Gefen Home Theater Scaler allows you to upscale and switch your standard definition or high definition component sources to resolutions up to 1080p. Anything from set-top boxes, DVD players to the next generation of gaming consoles including the Xbox 360 and PS3 can be plugged into the Home Theater Scaler. -
Page 5: Features
• Dual 3-D motion video adaptive de-interlacers with smooth low-angle edge. • Automatic 3:2 pull-down & 2:2 pull-down detection and recovery. • Operates through on-screen OSD menu control and remote control. Includes: (1) Home Theater Scaler (1) 6 ft HDMI cable (M-M) (1) 5V Power Supply (1) IR Remote control (1) User’s Manual... -
Page 6: Panel Layout
PANEL LAYOUT Component Input 1 Component Input 2 Analog Audio Analog Audio Power Input 2 Input 1 On/Off Connects 5V Digital Audio and Digital Audio and Digital Audio and Power Supply HDMI Input 3 HDMI Output HDMI Input 4 IR Eye... -
Page 7: Operation Controls And Functions
Y-Cb/Pb-Cr/Pr input connector of the Home Theater Scaler. When connecting to a DVI source, use an DVI to HDMI cable (or adaptor) to connect the DVI output of a STB or DVD to the HDMI input connector of the Home Theater Scaler. -
Page 8: Operation Controls And Functions
OPERATION CONTROLS AND FUNCTIONS After you power on the unit, press the menu button and it will bring up the main menu as follows: Video (or PC): When Video is selected, a sub menu as shown below, will come up. -
Page 9: Operation Controls And Functions / Color Settings
OPERATION CONTROLS AND FUNCTIONS Picture mode: There are 4 picture modes for the user to choose from. User: Select to adjust to your favorite setting and store it. Standard: Standard factory default setting for optimal display in a normal environment. Vivid: High saturation picture for optimal display in a bright room. -
Page 10: Output Settings / Osd Adjustment / Information
Output: The Home Theater Scaler can output a wide variety of PC and HD resolutions as follows. DVI/HDMI (up to 165 mhz) 480i 480p 576i 576p 720p @ (50/60) 1080i @ (25/30) 1080p @ (50/60) VGA @ 60 SVGA @ 60... -
Page 11: Using The Home Theater Scaler
*Note for computers connected to the Home Theater Scaler - When your com- puter boots up, it looks for an EDID (extended display identification data) from the display to tell it what monitor is connected and what resolution to output. During boot up of the computer you should have the DVI input selected so that the com- puter gets the EDID of the display that is selected. -
Page 12: Rmt-Sr-Ir Installation
RMT-SR-IR INSTALLATION 1. Remove battery cover from the back of the RMT-SR-IR remote. 2. Verify that dip switches 1 & 2 are in the down (OFF) position. 3. Insert the battery, hold the battery so that you can see the positive side facing up. The side that is not marked must be facing down. -
Page 13: Pin Configuration
HDMI Output Pin Assignment Pin # Function Assignment TMDS Data2+ TMDS Data2- TMDS Data1 Shield TMDS Data0+ TMDS Data0- TMDS Clock Shield DDC/CEC Ground Hot Plug Detect PIN CONFIGURATION Pin # Function Assignment TMDS Data2 Shield TMDS Data0 Shield Reserved (N.C. on device) TMDS Data1+ TMDS Data1- TMDS Clock+... -
Page 14: Specifications
SPECIFICATIONS Digital Video Amplifier Bandwidth...1.65 Gbps Component Video Bandwidth...350 Mhz Input DDC Signal...5 volts p-p (TTL) Input Video Signal...1.2 volts p-p Single Link Range...1080p/1920 x 1200 Input/Output HDMI Connector...type A 19 pin female Component Video Connector...3 RCA Digital Audio Connector...Optical TOSlink + Coax SPDIF Analog Audio Connector...2 RCA Power Supply...5V DC Power Consumption...20 watts (max) -
Page 15: Terminology
TERMINOLOGY Short form for Display Data Channel. It is a VESA standard for communication between a monitor and a video adapter. Using DDC, a monitor can inform the video card about its properties, such as maximum resolution and color depth. The video card can then use this information to ensure that the user is presented with valid options for configuring the display.
