Features - Gefen EXT-HDMI1.3-2-3GSDIS User Manual

HDMI 1.3 Features Supported:
• 225 MHz Video Bandwidth
• 10-bit Deep Color
• xvYCC
• Up to 8 channels of PCM audio embedded into HDMI
• Dolby Digital/DTS AC3 encoded audio

Features

• 10-bit resolution for greater precision and dynamic range
• Proprietary motion adaptive video de-interlacing with edge interpolation for
SD/HD formats
• Supports 8 channels of SDI audio
• Advanced noise reduction and detail enhancement
• Fully integrated sprite-based multi-plane OSD controller
• Frame rate conversion to / from any refresh rate
• Pattern mode w/ color bars & coarse hatch patterns
• Color correction
• Input color range can be controlled
• Noise Reduction
• Detail Enhancement
• Brightness Adjustment
• Gamma Selection
• Aspect Ratio Select
• French/English Menu Set
• USB-upgradeable fi rmware
• Remote control via IR remote control and/or RS232 serial port
• 3GSDI level A/B (4:2:2 color space only)
Package Includes
(1) HDMI 1.3 to 3GSDI Scaler
(1) 6 ft. HDMI cable (M-M)
(1) 6 ft. DB9 Serial Cable (M-F)
(1) IR Remote Control Unit
(1) 5V DC Locking Power Supply
(1) Set Rack Ears
(1) User Manual
FEATURES
3
