  • Page 1 Cannon CANTERBURY INBUILT MODELS USER INSTRUCTIONS INSTALLATION INSTRUCTIONS This heater is approved for use with Natural and Propane gases. SERVICE INSTRUCTIONS Please leave instructions with the owner...
  • Page 2: Table Of Contents

    Contents Contents Warranty ❍ Distributor Safety warnings ❍ What to do if you smell gas ❍ Warnings ❍ Standards User instructions ❍ Operating instructions ❍ Cleaning ❍ Flame characteristics Heater specifications Installation instructions 10-15 ❍ Clearances ❍ Installation into a masonry/brick or mock fireplace ❍...
  • Page 3: Warranty

    Warranty The Cannon appliance is warranted against defects in materials and work- manship for a period of one, (1) year from its date of original purchase, for residential use in Australia. Warranty service, which includes parts and labour for the replacement or repair of defective parts, is available through the CANNON distributor.
  • Page 4: Safety Warnings

    Refer to other sections of this manual for correct procedures, or consult with place of purchase, a licensed plumber, a gas supplier or the CANNON distributor listed in this manual. 2. Do not build the heater into bookcases or walls. Install only in loca- tions as referred to in these installation instructions.
  • Page 5: Standards

    Before testing the flue confirm air vents are unobstructed. If an exhaust fan or other heating appliances are present switch them on. This is to test that there is no interaction between the Cannon heater and other appliances. Refer AS5601.
  • Page 6: User Instructions

    User instructions Operating instructions 1. Plug the power cord into the wall socket and turn on the power to the heater, see figure 1. Refrain from using an extension cord. 2. For control lay-out refer to figure 2 3. To turn heater on press switch to POWER ON position. There is a 5 second delay before the burner ignites.
  • Page 7 5. To increase the fan speed to MED, press switch for MED setting. Refer figure 5. 6. To increase the fan speed to HIGH, press switch for HIGH setting. Refer figure 6. 7. To turn the burner to LOW setting, press switch for LOW setting. Refer figure 7.
  • Page 8: Cleaning

    Cleaning All cleaning should be carried out when the heater is cold. Normally the heater should only need wiping with a lint - free damp cloth. Any stubborn stains can be removed with a non-abrasive spray on cleaner. If an abrasive cleaner is used the paint finish will be damaged.
  • Page 9: Heater Specifications

    Heater specifications Gas type: Natural or Propane gas, as indicated Note: on data label The data plate is located on Gas consumption: 26 MJ/hr input the fan chamber base, rear of the lower fascia. Energy output: 21.45 MJ/hr (5.96 kW) Energy star rating: 4 stars Heater type:...
  • Page 10: Installation Instructions

    If installing into a mock fireplace a mock fireplace installation kit MUST be used. The mock fireplace instal- lation kit can be ordered from the CANNON distributor. Order speci- fication for the part is ‘MOCKKITRO’.
  • Page 11: Installation With A Flue Connected

    Refer AS5601. For “air movement not to affect appliance” see clause 5.3.1. For ‘air supply to appliance’ see clause 5.4.1. For ‘ventilation requirements’ see clause .5.4.3. Installation WITH a flue connected...
  • Page 12: Installation Without A Flue Connected

    Installation WITHOUT a flue connection.
  • Page 13 6. Prepare electrical and gas connections. Remove the lower front cover, see figure 16. A 10 Amp wall socket needs to be located within 1.5m of the heater. If using a power point in the chimney, route the plug and cord through cord access at lower LH side of rear panel.
  • Page 14: Sealing

    11. Remove the inner glass. Slacken off screws in top clamp and remove side clamps. Refer figure 20. Sealing 12. All gaps between heater case and fireplace are to be sealed. Seal with foam tape around top and sides of heater flange as required.
  • Page 15: Gas Connection

    Gas connection 13. Slide heater into the fireplace ensuring that gas inlet pipe is fed through the hole at the rear bottom RHS of the heater. Refer figure 22 and gas connection figure 24. 14.With heater in position, flanges should be hard against masonry. Se- cure case flanges to masonry.
  • Page 16: Log Installation

    Log installation 16. The burner is contained within the burner chamber. Refer figure 25. 17. Carefully unpack the log set. Logs are numbered as follows: No 1 - Left front log No 2 - Left back log No 3 - Right front log No 4 - Right back log Position the four individually numbered logs in the following order on the burner head as shown in figure 26-29.
  • Page 17: Gas Control

    18. Refit the inner glass, making sure not to overtighten the screws. Advise the user in the operation of the 19. Refit the front glass surround. Ensure that the glass surround is replaced heater the correct side up. The rearward sloping frame must be at the top and the vertical ledge must be at the bottom.
  • Page 18: Gas Pressure Point

    Gas pressure point 24.The pressure point is closed with a captive screw. Turn screw 6 revolu- tions anticlockwise to open the pressure point as indicated on figure 33(a) and place manometer tube over the test point as per figure 33(b). Gas pressure adjustment 25.Switch the top two control buttons to “Full On”...
  • Page 19: Installation Tips

    ❍ Test the operation of the chimney before installing the new heater. ❍ Be careful! CANNON heaters are high efficiency products with low flue gas tempera- tures (typically 100°C) so if you are replacing an older type radiant heater with a much higher flue gas temperature (150°C or higher) make sure of the integrity of the fireplace and chimney before installing the new CANNON log fire.
  • Page 20: Service Instructions

    Service instructions (Do not modify this appliance) General 1. Service work to be carried out by an authorised service person only. 2. Unplug from wall socket or turn off power at main switchboard if heater is hard wired. 3. Always shut off the gas supply and ensure that the heater is cool before commencing any service operations.
  • Page 21: To Replace The Fan

    2. Disconnect the fan plug from the plug carrier. Remove the two M5 wing nuts which locate the fan to the fan chamber underside. Lower fan from male thread. 3. Disconnect the silicon tube from the fan pressure switch, rotate the fan scroll 90°...
  • Page 22: Trouble-Shooting

    Trouble-shooting (Do not modify this appliance) To check the operation of the electronic (module) controller (Type 537 ABC or Type DBC 579) you will require a digital multimeter with the functions to measure AC/DC voltage, continuity, resistance and micro-amps. It is critical that the appliance is earthed and that the active and neutrals are not reversed. Item No Check Action...
  • Page 23: Connections

    Sparks, ignites on low flame • Check that the wall socket to the appliance has then extinguishes after 10 correct polarity. Do not use an extension cord. Check seconds. Continues to spark polarity in the electrical supply lead to appliance. during flame presence.
  • Page 24 Data label Date installed: ........Compliance Certificate No ......For service to this appliance For service to this appliance or spare parts contact the CANNON distributor: Sampford IXL (spare parts) Cannon 52 - 70 Sparks Avenue Fairfield, Vic, 3078 Phone: 1300 727 421...
