Cannon
MOCK FIREPLACE
INSTALLATION
INSTRUCTIONS
TO SUIT MOCK FIREPLACE
INSTALLATIONS
CANTERBURY
INBUILT MODELS
INSTALLATION INSTRUCTIONS
FOR FITMENT INTO A
COMBUSTIBLE ENCLOSURE
Read these instructions in conjunction
with heater installation instructions
Cannon
Part No: F2663
Gmk10025
This heater is approved for use with
Revision J -March 2010
AS4553:2008
Natural or Propane gases.
Advertisement
Related Manuals for Cannon Canterburry
Summary of Contents for Cannon Canterburry
- Page 1 Cannon MOCK FIREPLACE INSTALLATION INSTRUCTIONS TO SUIT MOCK FIREPLACE INSTALLATIONS CANTERBURY INBUILT MODELS INSTALLATION INSTRUCTIONS FOR FITMENT INTO A COMBUSTIBLE ENCLOSURE Read these instructions in conjunction with heater installation instructions Cannon Part No: F2663 Gmk10025 This heater is approved for use with...
- Page 2 CONTENTS INSTALLATION INTO A COMBUSTIBLE ENCLOSURE MOCKKITRO ( SINGLE SKIN FLUE ) METHOD B ITEM PAGE. General METHOD. Mock fireplace enclosure recommendations age 2 1. Mark out vertical centre-line of flue outlet on rear of enclosure. Mock cavity dimensions - Canterbury age 3 2.
- Page 3 GENERAL INSTALLATION INTO A COMBUSTIBLE ENCLOSURE MOCKKITRO ( SINGLE SKIN FLUE ) METHOD B 600 mm BETWEEN This heater shall only be installed by an authorised person. This TOP OF COWL AND appliance shall be installed in accordance with the NEAREST PART OF ROOF FLUE COWL manufacturers installation instructions.
- Page 4 MOCK FIREPLACE ENCLOSURE RECOMMENDATIONS METHOD A 345 mm TO 610 mm STUD STUD MOCKKITRA The enclosure can be fabricated using any standard building FLUE OPENING materials, providing that spacer brackets are fitted to the heater to provide adequate clearances to combustible 44 mm GAS INLET 600 mm MIN...
- Page 5 INSTALLATION INTO WALL CAVITY. ( TWIN SKIN FLUE ) MOCK CAVITY DIMENSIONS - CANTERBURY MOCKKITRA METHOD A The minimum wall cavity depth required is 450mm. Select a pair of studs in front of which the heater is to be installed. The gap between the studs should be no less than 345mm and no greater than 610mm.
- Page 6 OVERALL DIMENSIONS OF THE HEATER CABINET FITMENT OF SPACER BRACKETS AND BLANKET (SEE FIG 3 AND 4. ) 1. Fit top and side brackets to heater cabinet on diagonal corners * HEIGHT 620 mm (Including spacers) as shown each side. (see Fig 5). Use existing screw positions. * WIDTH 735 mm (Including spacers)
