RENESAS MCU
32
RX Family / RX600 Series / RX62N Group
All information contained in these materials, including products and product specifications,
represents information on the product at the time of publication and is subject to change by
Renesas Electronics Corp. without notice. Please review the latest information published by
Renesas Electronics Corp. through various means, including the Renesas Electronics Corp.
website (http://www.renesas.com).
Renesas Demonstration Kit (RDK) for RX62N
User's Manual: Hardware
i
REU10B0009-0100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RX Family and is the answer not in the manual?

Questions and answers

Related Manuals for Renesas RX Family

Summary of Contents for Renesas RX Family

  • Page 1 All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Renesas Electronics Corp. without notice. Please review the latest information published by Renesas Electronics Corp. through various means, including the Renesas Electronics Corp.
  • Page 2 Renesas or its affiliates be liable for any other direct or indirect special, incidental or consequential damages arising out of or in relation to the use of this RDK, even if Renesas or its affiliates have been advised of the possibility of such damages.

  • Page 3: Table Of Contents

      Table of Contents 1. Preface..........................1   2. Purpose..........................2   3. Power Supply ........................4   3.1. Requirements......................... 4   3.2. Power – Up Behavior ..................... 4   4. Board Layout........................5   4.1. Component Layout ......................5  ...
  • Page 4   11. Component Placement....................24   12. Additional Information....................25   12.1. Hardware Partner Information ..................25   Renesas Contact Information....................37  ...

  • Page 5: Preface

    All brand or product names used in this manual are trademarks or registered trademarks of their respective companies or organizations. Copyright © 2010 Renesas Electronics America, Inc. All rights reserved. © 2010 Renesas Electronics Corporation. All rights reserved. © 2010 Renesas Solutions Corporation. All rights reserved.

  • Page 6: Purpose

    Chapter 2. Purpose This RDK is an evaluation and demonstration tool for Renesas RX62N microcontrollers. The goal is to provide the user with a powerful debug and demonstration platform targeted at common applications. A set of human/machine interfaces are tightly integrated with the features of the RX62N and the software demonstration programs providing the user with an accessible platform to rapidly evaluate and customize.
  • Page 7 The Renesas RDK user experience is complemented by the online Renesas ecosystem: • Renesas Interactive: www.RenesasInteractive.com o Free Online Learning • Renesas Rulz: www.RenesasRulz.com o Online community o Online user forums o www.RenesasRules.com/RX62N - Online support site for this RDK •...

  • Page 8: Power Supply

    When the RDK is purchased it has the ‘Release’ or stand-alone code from Example #4 pre-programmed into the Renesas microcontroller. The code exercises the user LEDs, LCD, PWM, ADC, Potentiometer, and Ethernet interfaces. The LCD powers up with the message: “Micrium”, “uC/OS-III”, “uC/TCP-IP” message. If the Ethernet interface is active, and a DHCP server is present, the RDK will receive an IP Address, subnet mask and Gateway address.

  • Page 9: Board Layout

    Chapter 4. Board Layout 4.1. Component Layout The following diagram shows the top layer component layout. Figure 4-1: Board Layout...

  • Page 10: Board Dimensions

    4.2. Board Dimensions The following diagram gives the board dimensions and connector positions. All through hole connectors are on a common 0.1” grid for easy interfacing. Figure 4-2: Board Dimensions...

  • Page 11: Block Diagram

    Chapter 5. Block Diagram Figure 5-1 shows the CPU board components and their connectivity. Power Jack Extension Headers USB I/F Segger J-Link Lite RCAN Debugger RS-232 RX62N Debug LCD Boot mode pins Boot Modes RESn Ethernet (1588) Reset pin IRQ pin IRQ pin IRQ pin USB (Host, Dev, OTG)
  • Page 12 Figure 5-2 shows host PC connection to the RDK board. Figure 5-2: RDK Connections...

  • Page 13: User Circuitry

    Chapter 6. User Circuitry 6.1. Switches There are five switches located on the CPU board. The function of each switch and its connection are shown in Table 6-1. Switch Function Microcontroller Connects to an IRQ line for user controls. IRQ8, Pin 95 Connects to an IRQ line for user controls.

  • Page 14: Debug Lcd Module

    6.2.Debug LCD Module A debug LCD module is supplied on the RDK. The debug LCD module uses an SPI interface to reduce the pin allocation. Software contrast control is also provided. The module supplied with the RDK uses 3.3v. The display is a 96 x 64 graphics display and uses a white LED backlight.

  • Page 15: Micron Serial Flash

    Table 6-3, below, shows the user LED pin references and their corresponding microcontroller port pin connections. LED Reference (As shown Color Microcontroller Port Pin & Microcontroller on silkscreen) Pin Number LED4 (Up) Green LED6 LED6 (Un) LED3 LED8 (Vp) Green LED5 LED10 (Vn) LED2...

  • Page 16: Audio (Audio Out, Mic, Speaker, Volume Potentiometer)

    The RCAN module can be controlled by the MCU through the CTx0 (Port pin P32) and CRx0 (Port pin P33) lines, or controlled externally through the header connections CTx0 and CRx0. The Table 6-5 contains details of the specific pin functions and their locations. Note that an 8 pin Renesas R2A25416SP CAN transceiver is fitted to the board. Description...

  • Page 17: Usb

    6.9. USB The USB module can be configured as Host, Device or OTG with the correct switch settings on SW6. Function / Device / Slave mode: This mode does not take any external power circuitry to implement. Simply put the SW6 DIP switches to the proper setting as in table 6-7 and configure the software appropriately.

  • Page 18: Ethernet

    USB DIP Switch Settings (SW6) Mode No. SW6.1 SW6.2 SW6.3 SW6.4 USB Host USB Function / device/ slave USB On the Go (OTG) Table 6-7: USB DIP Switch SW6 settings 6.10. Ethernet The Ethernet module conforms to the Ethernet or IEEE802.3 media access control (MAC) standard. Ethernet controller is connected to the direct memory access controller for Ethernet controller (E-DMAC) and carries out high-speed data transfer to and from the memory.

  • Page 19: Axis Accelerometer

    ® The National Semiconductor 10/100 DP83640 Precision PHYTER Ethernet PHY supports the IEEE1588 Precision Time Protocol (PTP) providing precision clock synchronization for real-time industrial connectivity. The RDK includes a GPIO/Interrupt connection between the PHY and the RX62N for PTP event processing, and a direct LED connection for timing indications.
  • Page 20 Table 6-10 below describes the function of the jumper headers. Jumper Settings Reference Function Open Short Notes Speaker Headphone Active Speaker Enabled Headphones may work to some Enable extent with jumper fitted – but will not work optimally Removes the CAN termination CAN terminator active Cut the trace between the pads terminator...

  • Page 21: Oscillator Sources

    6.14. Oscillator Sources All crystals are provided by Epson Electronics America. A crystal is fitted on the RDK and used to supply the main clock to the Renesas microcontroller. Table 6-11 details the crystals that are fitted on the RX62N RDK. Component...

  • Page 22: Modes

    Chapter 7. Modes This RDK supports the 3 CPU modes: Single Chip Mode, Boot Mode and USB Boot Mode. These modes are selected by SW5 MD0 and MD1 pins. Placing the switch in the ‘On’ position sets the value to a logic ‘0’, and the ‘Off’ position sets the value to a logic ‘1’.

  • Page 23: Programming Methods

    J-Link disable 2-pin header. This is useful if the board needs to be put into either USB or UART boot mode. The J-Link Lite is located in the upper left section of the RX62N RDK. Should the Segger Micro become inoperable – it will need to be returned to Renesas for repair.

  • Page 24: Headers

    Chapter 9. Headers 9.1. Extension Headers Table 9-1 shows the controller pin headers and their corresponding microcontroller connections. The header pins connect directly to the microcontroller pin. JN1 Extension Header Circuit Net MCU Pin Circuit Net Name MCU Pin Name Ground Ground 3V3A...
  • Page 25 JN2 Extension Header Circuit Net Name Circuit Net Name MCU Pin RSTOUT# P53/BCLK P35/NMI Ground P54/PWMLP PD0/LED1 PD1/LED2 PD2/LED3 PD3/LED4 PD4/LED5 PD5/LED6 PD6/LED7 PD7/LED8 PE0/LED9 PE1/LED10 PE2/LED11 PE3/LED12 Table 9-2: JN2 Extension Header * The RSTOUT# signal connects to the MCU via a the U3A buffer PIN 49 J8 Application Header Circuit Net Name MCU Pin...

  • Page 26: Code Development

    The GNU Toolchain has NO restrictions and was used with ALL the Micrium uC/OS-III example projects. The Renesas Toolchain is fully functional for a period of 60 days from first use. After the first 60 days of use have expired, the compiler will default to a maximum of 128k (code and data). To use the Renesas toolchain with programs greater than this size you will need to purchase the full version tools from your Renesas distributor Warning: The protection software for the compiler will detect changes to the system clock.

  • Page 27: Memory Map

    10.4. Memory Map H’0000 0000 On-Chip RAM H’0001 8000 Reserved Area H’0008 0000 Peripheral I/O Registers H’0010 0000 On-chip ROM (data flash) H’0010 8000 Reserved Area H’007F 8000 FCU-RAM H’007F A000 Reserved Area H’007F C000 Peripheral I/O Registers H’007F C500 Reserved Area H’007F FC00 Peripheral I/O Registers...

  • Page 28: Component Placement

    Chapter 11. Component Placement Table 11-1: Component Placement – Front view...

  • Page 29: Additional Information

    Chapter 12. Additional Information 12.1. Hardware Partner Information Hardware partners played an integral role in the definition, development, and deployment of this RDK. Without their numerous contributions, this project would not have been possible. Contributors include National Semiconductor for the DP83640 Precision PHYTER - IEEE1588 Precision Time Protocol Ethernet transceiver and their LM4808 audio amplifier and LM1117 3.3v regulator.
  • Page 30        ...
  • Page 31    ...
  • Page 32      ...
  • Page 33        ...
  • Page 34  ...
  • Page 35  ...
  • Page 36        ...
  • Page 37    ...
  • Page 38          ...
  • Page 39    ...
  • Page 40  ...

  • Page 41: Renesas Contact Information

    For information about the RX62N assembly language, refer to the RX Series Software Manual. Online technical support and information is available at: http://www.renesas.com/renesas_starter_kits Technical Contact Details America: techsupport.rta@renesas.com Europe: tools.support.eu@renesas.com Japan: csc@renesas.com General information on Renesas Microcontrollers can be found on the Renesas website at: http://www.renesas.com/...
  • Page 42             Renesas Demonstration Kit (RDK) for RX62N User's Manual Publication Rev.1.0 Sept 2010 Date Published by: Renesas Electronics America, Inc. 2880 Scott Boulevard Santa Clara, CA 95050-2554, U.S.A ©2010 Renesas Electronics America, All Rights Reserved.
  • Page 43                                                       Renesas Electronics America, Inc. 2880 Scott Boulevard REU10B0009-0100 Santa Clara, CA 95050-2554, U.S.A...
