Summary of Contents for Renesas RTK5RX65N0C00000BR
Page 1
All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Renesas Electronics Corporation without notice. Please review the latest information published by Renesas Electronics Corporation through various means, including the Renesas Electronics Corporation website (http://www.renesas.com).
Page 2
11. This document shall not be reprinted, reproduced or duplicated in any form, in whole or in part, without prior written consent of Renesas Electronics.
Page 3
Precautions The following precautions should be observed when operating Target Board for RX65N product: The Target Board is only intended for use in a laboratory environment under ambient temperature and humidity conditions. A safe separation distance should be used between this product and any sensitive equipment. Its use outside the laboratory, classroom, and study area or in area not conform to the protection requirements of the Electromagnetic Compatibility Directive could lead to prosecution.
Page 4
The revision history only shows the summary of revised or added parts, and does not include all revisions. Refer to the text in this manual for details. The following documents apply to the RX65N Group, RX651 Group. Make sure to use the latest versions for reference, available on the Renesas Electronics Web site. Document Type Description Document Title Document No.
Page 5
Personal Computer Digilent Pmod™ Compatible connector. Pmod™ is registered to Digilent Inc. Pmod™ Digilent-Pmod_Interface_Specification Random Access Memory Renesas Flash Programmer Read Only Memory Serial Peripheral Interface Universal Serial Bus All trademarks and registered trademarks are the property of their respective owners.
Rev.1.01 Jul 20, 2018 1. Overview Contents Thank you for purchasing the Renesas evaluation tool " Target Board for RX65N ". This product consists of the following item. Target Board for RX65N Purpose The Target Board for RX65N is an evaluation tool for Renesas microcontrollers. This manual describes the technical details of the Target Board for RX65N hardware.
Target Board for RX65N 4. Operating Environment 2. Board Layout Figure 2-1 shows the external appearance of the top side of Target Board for RX65N. External MCU Header Power Supply Header Evaluation Connector Reset Switch Power Indicator LED User Switch Current Consumption Measurement...
Target Board for RX65N 3. Parts Layout 3. Parts Layout Figure 3-1 shows the parts layout of Target Board for RX65N. 2.54mm 2.54mm 5.08mm 90mm Figure 3-1: Parts Layout R20UT4167EJ0101 Rev.1.01 Page 10 of 24 Jul 20, 2018...
Figure 4-1 shows the operating environment of the Target Board for RX65N. Install the integrated development environment (IDE) from the following URL on the host PC. All the other required drivers are will be automatically installed with the IDE. https://www.renesas.com/rxtb USB Cable Target Board for RX65N...
Reset: Reset switch, IDE reset instruction USB Connector The connector shape is USB mini -B for Integrated Development Environment (IDE) and for Renesas Flash Programmer (RFP). Connect to the computer via the USB cable. If the power supply on the host side is ON, the Target Board for RX65N will be automatically power-supplied with the cable connection.
Target Board for RX65N 5. User Circuit Pmod™ Connector The Pmod ™ connector (PMOD1) has a through hole at a pitch of 2.54 mm and is connected to the evaluation MCU according to Pmod™ Interface Type 2 A. Note that the Pmod ™ connector has the pin assignment different from other headers.
Target Board for RX65N 5. User Circuit External Power Supply Header When operating the evaluation MCU at an arbitrary voltage, or requiring current more than the USB current capacity, use the external power supply header (J4) for power supply. The available voltage depends on the evaluation MCU.
Target Board for RX65N 5. User Circuit Current Consumption Measurement Header The current consumption measurement header (JP2) is used for measuring current consumption of the evaluation MCU. The current consumption can be measured by connecting an ammeter to the evaluation MCU.
Target Board for RX65N 5. User Circuit 5.13 Emulator Reset Header The emulator enters the forced reset state by short-circuiting the emulator reset header (EJ2). The evaluation MCU can be operated independently without controlling the IDE. Figure 5-7 shows the emulator reset header position.
Target Board for RX65N 6. Configuration Configuration Modifying the Target Board for RX65N This section describes how to change the Target Board for RX65N setting by using option link resistance. An option link resistor is a 0Ω surface mount resistor, which is used to short or isolate a part of circuits. See the 6.2 below for the list of option links by function.
Target Board for RX65N 7. Handling Precautions Handling Precautions Board Thickness Please be extra careful when handling the “Target Board for RX65N “ as the board is thin (0.8 mm). Additional Load When adding loads by USB power supply, the maximum operational current is 300 mA at 3.3 V operation. When adding loads by external power supply, the maximum operational current is 500 mA under any operating voltage.
Target Board for RX65N 8. Code Development Code Development Figure 8-1 shows the setting of e2 studio when creating a new project for the Target Board for RX65N. Debug hardware: Select [E2 Lite (RX)]. Connection type: Select [Fine]. (JTAG connection is not available) Power supply from the emulator: Select [No].
Page 21
REVISION HISTORY Target Board for RX65N User’s Manual Description Rev. Date Page Summary 1.00 Oct 13, 2017 First Edition issued Section 1.4 Changes URL. Changes the wording. Section 1.6 Adds Block Diagram. Section 5.2 Clarified the application. 1.01 Jul 20, 2018 Section 7.4 Removes Communication with RFP.
Page 22
Target Board for RX65N User’s Manual Publication Date: Rev. 1.00 Oct 13, 2017 Rev. 1.01 Jul 20, 2018 Published by: Renesas Electronics Corporation...
