RX660 Group
32
RENESAS 32-Bit MCU
RX Family / RX600 Series
All information contained in these materials, including products and product specifications,
represents information on the product at the time of publication and is subject to change by
Renesas Electronics Corp. without notice. Please review the latest information published by
Renesas Electronics Corp. through various means, including the Renesas Electronics Corp.
website (http://www.renesas.com).
www.renesas.com
Renesas Starter Kit for RX660
Rev.1.00 Jan 2022
User's Manual
