Table 8.

BIOS Setup Menu Display

When you see this:
An option is grayed out and not accessible
The rest of this section lists the features that display onscreen after you press <F2> to
enter BIOS Setup. We do not describe all the option choices because (1) a few are not user
selectable but displayed for your information, and (2) many of the choices are relatively self-
explanatory.

Main Menu

Feature
System Time
System Date
Floppy Disk A:
Hard Disk Pre-delay
Primary IDE Master
Primary IDE Slave
Processor Settings
Language
Primary IDE Master and Slave Submenu
Feature
Type
Multi-Sector
Transfers
LBA Mode
Control
PIO Mode
Ultra DMA
Mode
MAXDATA PLATINUM Server Board User's Manual
Choices
HH:MM:SS
MM/DD/YYYY
Not Installed
1.44/1.25 MB/1.2 MB 3˚"
2.88 MB 3˚"
Disabled
Enabled
Press <Enter>
Press <Enter>
Press <Enter>
English (US)
French
Spanish
German
Italian
Choices
None
Auto
Disabled
2, 4, 8, or 16 sectors
Disabled
Enabled
Standard
1, 2, 3, 3/DMA 1,
4, 4/DMA 2
Mode 2
Mode 4
What it means:
You cannot change or configure the option in that
menu screen for one of the following reasons:
• The option is auto-configured or auto-detected.
• The field is informational only.
• The field is password protected and is accessible
only by the User or Administrator
Description
Sets the system time.
Sets the system date.
Selects the diskette type.
Causes the BIOS to insert a delay before
attempting to detect IDE drives in the system
Enters submenu.
Enters submenu.
Enters submenu.
Selects which language BIOS displays.
Description
Informs the system to ignore this drive.
Allows the system to attempt auto-detection of the drive type.
Determines the number of sectors per block for multisector
transfers. For Type Auto, this field is informational only.
For Type Auto, this field is informational only.
Displays the method for moving data to/from the drive.
This field is informational only.
43
