Boot Menu

Feature
Quiet Boot
Enabled
Boot Device Priority
Hard Drive
Removable Devices
ATAPI CDROM Drives
Boot Device Priority Submenu
Use the up- or down-arrow keys to select a device. Press the <+> or <-> keys to move the
device higher or lower in the boot priority list.
Boot Priority
st
1 Boot Device
nd
2 Boot Device
3 rd Boot Device
4 th Boot Device
Hard Disk Submenu
For options on this menu, use the up or down arrow keys to select a device. Press the <+>
or <-> keys to move the device higher or lower in the boot priority list.
Option
1. Drive #1 (or actual drive string)
2. Other bootable cards
Removable Devices Submenu
For options on this menu, use the up or down arrow keys to select a device.
Feature
Lists Bootable Removable
devices in the system.
50
Choices
Disabled
Press <Enter>
Press <Enter>
Press <Enter>
Press <Enter>
Device Description
Removable Devices Attempts to boot from a removable media device.
Hard Drive Attempts to boot from a hard drive device.
ATAPI CD-ROM Drive Attempts to boot from an ATAPI CD-ROM drive.
®
Intel Boot Agent version 4 Attempts to boot from a network when a network device
controlled by a PXE compliant ROM is present in the system.
Description
Other bootable cards cover all the boot devices not reported to
the system BIOS through BIOS Boot Specification mechanisms.
It may or may not be bootable, and may not correspond to any
device.
(additional entries for each drive that has a PnP header)
Option
Select one of the
detected devices
Description
Disabled, displays normal POST messages. Enabled, dis
plays OEM Logo instead of POST messages. Enabling this
option disables serial redirection.
Enters submenu.
Enters submenu.
Enters submenu.
Enters submenu.
Description
This list includes legacy 1.44-MB floppy
drives and 120-MB floppy drives.
