PCI Configuration Submenu

Feature
USB Function
Onboard NIC 1
Onboard NIC 2
Onboard SCSI
Onboard R-IDE
Onboard Video
USB Function Submenu
Feature
USB Function
Onboard NIC1 and 2 Submenu
Feature
Onboard NIC
Embedded NIC ROM
Onboard SCSI Submenu
Feature
Onboard SCSI
Embedded LVD SCSI ROM
Onboard R-IDE Submenu
Feature
Onboard R-IDE
Onboard R-IDE ROM
MAXDATA PLATINUM Server Board User's Manual
Choices Description
Press <Enter> Enters Submenu
Press <Enter> Enters Submenu
Press <Enter> Enters Submenu
Press <Enter> Enters Submenu (SCSI model only)
Press <Enter> Enters Submenu (ATA model only)
Press <Enter> Enters Submenu
Choices Description
Enabled Enables the embedded USB controller.
Disabled
Choices Description
Enabled If enabled, the system uses the embedded NIC.
Disabled
Enabled Enables the device option ROM.
Disabled
Choices Description
Enabled Enables or disables embedded legacy SCSI controller hardware.
Disabled
Enabled Enables the device expansion ROM
Disabled
Choices Description
Enabled If disabled, the embedded R-IDE device is turned off
Disabled and the device resources are hidden from the system
Enabled
Disabled If enabled, initializes the embedded R-IDE device expansion ROM
45
