Processor

The SCB2 accommodates one or two Intel
PGA2 package. This processor uses the .13 micron technology and offers advanced
performance. The processor external interface operates at a maximum of 133 MHz. For a
complete list of supported processors see:
http://support.intel.com/support/motherboards/server/scb2

Memory

The system board contains six 168-pin DIMM slots each supporting 72 Bit ECC (64-bit main
memory plus ECC) registered SDRAM DIMMs (PC-133 compatible). Memory is two-way
interleaved and partitioned in three banks. You may install a minimum of 128 MB (64 MB x 2)
and as much as 6 GB.
The controller automatically detects, sizes, and initializes the memory array, depending on
the type, size, and speed of the installed DIMMs, and reports memory size and allocation to
the server via configuration registers.
NOTE
Use DIMMs that have been tested for compatibility with the server board. Contact your
sales representative or dealer for a current list of approved memory modules. Check the
Intel Customer Support website for the latest tested memory list:
®
http://support.intel.com/support/motherboards/server/scb2

PCI Riser Slots

The server board has two PCI riser slots, each capable of supporting 64 Bit/66-MHz PCI riser
cards. PCI features:
• Bus speed up to 66 MHz
• 32 Bit memory addressing
• 5 V/3.3 V signaling environment
• Burst transfers of up to 512 Mbps
• 8, 16, 32, or 64 Bit data transfers
• Plug and Play ready
• Parity enabled
10
® Pentium ® III processors with 512k cache in the FC
