System Management Submenu
Feature
Board Part Number
Board Serial Number
System Part Number
System Serial Number
Chassis Part Number
Chassis Serial Number
BIOS Revision
BMC Revision
Primary HSBP Revision

Console Redirection Submenu

Feature
Serial Console
Redirection
Serial Port
Baud Rate
Flow Control

Event Log Configuration Submenu

Feature
Clear All Event Logs
Event Logging
Critical Event Logging
MAXDATA PLATINUM Server Board User's Manual
Choices Description
N/A Information field only
N/A Information field only
N/A Information field only
N/A Information field only
N/A Information field only
N/A Information field only
N/A Information field only
N/A Information field only
N/A Information field only
Choices Description
Disabled If enabled, BIOS uses the specified serial port to redirect
Enabled the console to a remote ANSI terminal. Enabling this option will
disable the Quiet Boot option.
COM1 3F8 IRQ4 Serial port and IRQ designated for server management features.
COM2 2F8 IRQ3 Make sure these values are identical to those of Serial Port A and
B in the Peripheral Configuration Setup menu.
9600 Console Redirection, when enabled, uses the baud rate specified.
19.2k When the Direct Platform Control (DPC) shares the COM port
38.4k as console redirection, set the baud rate to 19.2k to match
115.2k DPC baud rate, unless the autobaud feature is used.
No flow control None, disallows flow control.
CTS/RTS is hardware based flow control.
XON/XOFF is software flow control.
CTS/RTS + CD is hardware based plus carrier-detect flow control.
CTS/RTS When DPC is sharing the COM port as Console Redirection,
XON/XOFF set the flow control to XON/XOFF or XON/XOFF+CD
CTS/RTS +CD depending whether a modem is used.
Choices Description
No Setting this option to YES will clear the DMI event log after a
Yes system reboot.
Enabled When enabled, all systems events are logged.
Disabled
Enabled If enabled, BIOS will detect and log events for system critical
Disabled errors. Critical errors are fatal to system operation. These errors
include PERR, SERR, ECC, Memory errors and NMI.
49
