  • Page 1 MAXDATA PLATINUM Server Board User’s Manual MAXDATA PLATINUM Server Board User’s Manual...
  • Page 2 MAXDATA PLATINUM Server Board User’s Manual...

  • Page 3: Table Of Contents

    Service Partition (Optional) ....................39 Configuration Utilities ......................39 System Software Update Sequence .................39 Hot Keys ..........................40 Power-On Self-Test (POST) ....................41 Using BIOS Setup ........................41 Record BIOS Setup Settings .....................42 If BIOS Setup Is Inaccessible ....................42 MAXDATA PLATINUM Server Board User’s Manual...
  • Page 4 Software Updates ........................71 Creating a Bootable Diskette ....................71 Software Update Package .....................71 Preparation ........................71 Extraction ..........................72 Updating ...........................72 Individual Updates .........................73 BIOS Upgrade Description ....................73 Firmware Update Utility Description .................75 FRU/SDR Load Utility Description ..................75 MAXDATA PLATINUM Server Board User’s Manual...
  • Page 5 7 Regulatory and Integration Information ............ 93 Product Regulatory Compliance ................... 93 Product Safety Compliance ....................93 Product EMC Compliance ....................93 Product Regulatory Compliance Markings ................93 EMC Notices ........................93 Europe (CE Declaration of Conformity) ................93 MAXDATA PLATINUM Server Board User’s Manual...
  • Page 6 Rear COM2 Port Adapter Pin-out ...................15 Software Security Features ....................18 Configuration Utilities .....................40 Hot Keys .........................40 BIOS Setup Menu Navigation ..................42 BIOS Setup Menu Display .....................43 Command Line Format ....................76 10. Configuration Jumper .....................87 11. Post Codes ........................88 MAXDATA PLATINUM Server Board User’s Manual...

  • Page 7: Description

    Two external USB ports, internal header providing two additional USB • One external serial port (RJ-45), one internal COM 1 header • One external SCSI port (SCSI server board only), one internal • Two NIC ports (RJ-45) Form Factor Server ATX form factor MAXDATA PLATINUM Server Board User’s Manual...

  • Page 8: Server Board Connector And Component Locations

    EE. ATA-100 connectors (ATA version only) Secondary processor socket SCSI connector (SCSI version only) Primary processor socket GG. Hard Disk Drive LED header Sys fan 2 connector Figure 1. Server Board Connector and Component Locations MAXDATA PLATINUM Server Board User’s Manual...

  • Page 9: Back Panel Connectors

    F. Yellow Status LED G. NIC 1 RJ-45 connector H. Green Status LED I. Yellow Status LED J. PS/2 keyboard/mouse connector K. RJ-45 serial port L. USB 2 connector Figure 2. Back Panel Connectors MAXDATA PLATINUM Server Board User’s Manual...

  • Page 10: Processor

    32 Bit memory addressing • 5 V/3.3 V signaling environment • Burst transfers of up to 512 Mbps • 8, 16, 32, or 64 Bit data transfers • Plug and Play ready • Parity enabled MAXDATA PLATINUM Server Board User’s Manual...

  • Page 11: Video

    With 4 drives attached to dual ATA-100 channels, two striped drive pairs can mirror each other (RAID 0+1) for storage capacity and data redundancy. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 12: Network Controller

    Using both on-board NICs in a team does not allow the use of NIC 1 for server management access. To support both network teaming features and server management features, a third NIC must be added and teamed to NIC 2. MAXDATA PLATINUM Server Board User’s Manual...
  • Page 13 If a Preferred Primary is not selected, PROSet will attempt to select the best adapter, based on adapter model and speed. Mixed Adapter Teaming AFT supports up to eight server adapters per team, in any mix. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 14: Keyboard And Mouse

    To accommodate either standard, the J6A2 jumper block located directly behind the rear RJ45 serial port must be jumpered appropriately according to which standard is desired. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 15: J6A2 Jumper Block For Dcd Signal

    Table 3. Rear COM2 Port Adapter Pin-out RJ45 Signal Abbreviation Request to Send Data Terminal Ready Transmitted Data Signal Ground SGND Ring Indicator Received Data DCD or DSR DCD/DSR 1 or 6 Clear To Send MAXDATA PLATINUM Server Board User’s Manual...

  • Page 16: Acpi

    Soft off: Only the RTC section of the CSB and the BMC are running in this state. No context is saved by the OS or hardware. CAUTION The system is off only when the AC power cord is disconnected. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 17: Security

    • May enter either password to boot the server if Password on Boot is enabled in either the BIOS Setup or SSU. • May enter either password to exit secure mode. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 18: Software Security Features

    To write protect access to diskette whether the server is in secure mode or not, use the Setup main menu, Floppy Options, and specify Floppy Access as read only. continued MAXDATA PLATINUM Server Board User’s Manual...
  • Page 19 If secure mode is enabled and the “Secure Boot Mode” option is also enabled, the server will fully boot but will require a password before accepting any keyboard or mouse input. MAXDATA PLATINUM Server Board User’s Manual...
  • Page 20 MAXDATA PLATINUM Server Board User’s Manual...

  • Page 21: Installation Procedures

    3. Hold the shield in place, and push it into the opening (B) until it is seated. Make sure the I/O shield snaps into place all the way around. Figure 5. Installing the I/O Shield MAXDATA PLATINUM Server Board User’s Manual...

  • Page 22: Rearrange The Standoffs

    Failure to properly rearrange the metal standoffs may cause the server board to malfunction and may permanently damage it. Your chassis may be different from the illustration. Figure 6. Rearrange the Standoffs MAXDATA PLATINUM Server Board User’s Manual...

  • Page 23: Server Board Bumpers

    Failure to install bumpers, or installing bumpers that are too tall or too short, may damage your board. DO NOT INSTALL server board bumpers in the Intel SR1200 and SR2200 server chassis. Figure 7. Installing Server Board Bumpers MAXDATA PLATINUM Server Board User’s Manual...

  • Page 24: Install The Server Board

    I/O openings. 2. Adjust board position to align mounting holes with standoffs. 3. Using the screws that came with your chassis, mount the board to the chassis. Figure 8. Installing the Server Board MAXDATA PLATINUM Server Board User’s Manual...

  • Page 25: Installing Processors

    2. Raise the locking bar on the socket. Figure 9. Raising the Locking Bar 3. Aligning the pins of the processor with the socket, insert the processor into the socket. 4. Lower the locking bar completely. Figure 10. Installing Processors MAXDATA PLATINUM Server Board User’s Manual...

  • Page 26: Installing The Heat Sink

    1. Following the instructions provided with the processor, install the fan on the processor heat sink. 2. Connect the fan to (A) if it is on the primary processor or to (B) if it is on the secondary processor. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 27: Install The Processor Terminator

    2. Aligning the two corner marks on the terminator with the handle-side of the socket (C), insert the terminator into the socket. 3. Lower the locking bar completely (D). Figure 14. Installing the Processor Terminator MAXDATA PLATINUM Server Board User’s Manual...

  • Page 28: Memory

    Installed DIMMs must be the same speed and must all be registered. For a list of supported memory, call your service representative or visit the Intel ® Support website: http://support.intel.com/support/motherboards/server Figure 15. Installing Memory MAXDATA PLATINUM Server Board User’s Manual...

  • Page 29: Connect Cables

    Fan module connector (7-pin) Fan connectors (system and processor) USB header Floppy connector (For use in a non Intel ® chassis only) COM 1 header Combined Floppy/Front Panel/IDE connector (For use in an Intel ® chassis only) MAXDATA PLATINUM Server Board User’s Manual...
  • Page 30 MAXDATA PLATINUM Server Board User’s Manual...

  • Page 31: Upgrading

    Use a conductive foam pad if available but not the board wrapper. Do not slide board over any surface. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 32: Memory

    Installed DIMMs must be the same speed and must all be registered. ® For a list of supported memory, call your service representative or visit the Intel Cus- tomer Support website: http://support.intel.com/support/motherboards/server/scb2 Figure 17. Installing DIMMs MAXDATA PLATINUM Server Board User’s Manual...

  • Page 33: Processors

    (1) Touch the metal chassis before touching the processor or server board. Keep part of your body in contact with the metal chassis to dissipate the static charge while handling the processor. (2) Avoid moving around unnecessarily. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 34: Adding Or Replacing A Processor

    8. Aligning the raised metal surfaces, place the heat sink on top of the processor. 9. Install the heat sink clip with pin (1) inserted into slot (2). 10. Slowly close the locking lever (A) until it contacts tab (B). Figure 19. Installing the Heat Sink MAXDATA PLATINUM Server Board User’s Manual...

  • Page 35: Attach The Heat Sink

    11. Following the instructions provided with the processor, install the fan on the processor heat sink. 12. Connect the fan to (A) if it is on the primary processor or to (B) if it is on the secondary processor. Figure 21. Connect the Heat Sink Fan MAXDATA PLATINUM Server Board User’s Manual...

  • Page 36: Removing A Processor

    4. To remove a terminator, pull it out of the socket and then replace the it with an other terminator or install a processor. 5. Lower the locking bar (B) completely. Figure 22. Installing a Terminator MAXDATA PLATINUM Server Board User’s Manual...

  • Page 37: Replacing The Back Up Battery

    9. Push the battery down – the metal retainer locks the battery in the socket. 10. Close the chassis. 11. Run Setup to restore the configuration settings to the RTC. 12. Restore your custom BIOS settings. Figure 23. Replacing the Back up Battery MAXDATA PLATINUM Server Board User’s Manual...
  • Page 38 MAXDATA PLATINUM Server Board User’s Manual...

  • Page 39: Configuration Software And Utilities

    When you update the system software, you should do it in the following order. 1. Update BIOS 2. Update firmware (BMC & HSC) 3. Update FRU/SDR 4. Unplug system for 30 seconds 5. Clear CMOS via front panel MAXDATA PLATINUM Server Board User’s Manual...

  • Page 40: Hot Keys

    Abort memory test during POST. <ESC> (Press while BIOS is updating memory size on screen.) Display a menu for selecting the boot device. <ESC> (Press anytime after memory check.) To remove the splash screen. <ESC> MAXDATA PLATINUM Server Board User’s Manual...

  • Page 41: Power-On Self-Test (Post)

    Defining the serial port(s) • Set time/date (to be stored in RTC) • Configure hard drive(s) • Specify boot device sequence • Enable SCSI BIOS • Enable Server Management Features • Setup system passwords MAXDATA PLATINUM Server Board User’s Manual...

  • Page 42: Record Bios Setup Settings

    Change the value of an item + or - Select an item or display a submenu <Enter> Leave a submenu or exit BIOS Setup <Esc> Reset to BIOS Setup defaults <F9> Save and exit BIOS Setup <F10> MAXDATA PLATINUM Server Board User’s Manual...

  • Page 43: Main Menu

    Control Enabled PIO Mode Standard 1, 2, 3, 3/DMA 1, 4, 4/DMA 2 Ultra DMA Mode 2 Displays the method for moving data to/from the drive. Mode Mode 4 This field is informational only. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 44: Advanced Menu

    Plug & Play O/S Selecting “No” lets the BIOS configure all the devices in the system. Selecting “Yes” allows the OS configure Plug and Play devices. NumLock Enables or disables the “Numlock” function at power up. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 45: Pci Configuration Submenu

    Enabled If disabled, the embedded R-IDE device is turned off Disabled and the device resources are hidden from the system Onboard R-IDE ROM Enabled Disabled If enabled, initializes the embedded R-IDE device expansion ROM MAXDATA PLATINUM Server Board User’s Manual...

  • Page 46: Memory Configuration Submenu

    #3 Memory Retest Disabled If enabled, BIOS will activate and retest all DIMMs on the next system boot. This option will be automatically reset Enabled to disabled on the next system boot. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 47: Security Menu

    Secure Mode Boot Disabled System boots in secure mode. Enabled The user must enter a password to unlock the system. This option only appears on the screen after a “user” password has been entered. continued MAXDATA PLATINUM Server Board User’s Manual...

  • Page 48: Server Menu

    POST Error Pause Disabled If enabled, the system will wait for user intervention on Enabled critical POST errors. Platform Event Filtering Disabled Enable/Disable triggers for system sensor events inside Enabled the Baseboard Management Controller (BMC). MAXDATA PLATINUM Server Board User’s Manual...

  • Page 49: Console Redirection Submenu

    Critical Event Logging Enabled If enabled, BIOS will detect and log events for system critical Disabled errors. Critical errors are fatal to system operation. These errors include PERR, SERR, ECC, Memory errors and NMI. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 50: Boot Menu

    For options on this menu, use the up or down arrow keys to select a device. Feature Option Description Lists Bootable Removable Select one of the This list includes legacy 1.44-MB floppy devices in the system. detected devices drives and 120-MB floppy drives. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 51: Exit Menu

    One of the selections on the popup Boot menu is “Enter Setup. ” Selecting this option brings you into the BIOS Setup. For more information about the BIOS Setup, see “Using BIOS Setup” 4. Press <Enter>. 5. The boot process continues. When finished, a system prompt displays. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 52: Permanently Changing The Boot Device Priority

    Use the following keys to navigate through the menus and submenus: SCSISelect Navigation Keys Press Exit the utility Enter Select an option Return to a previous option ¯ Move to the next option Switch between color and monochrome Reset to host adapter defaults MAXDATA PLATINUM Server Board User’s Manual...

  • Page 53: Configuring The Adaptec Aic-7899 Scsi Adapter

    Delete a RAID array • Restore a RAID array Running the Promise FastBuild Utility 1. When this message appears on the video monitor: <<<Press <Ctrl><F> to enter FastBuild (TM) Utility>>> 2. Press <Ctrl+F> to run the utility. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 54: Direct Platform Control (Dpc) Console

    Service Partition mode. Entered when the server reboots from the service partition and the DPC Console has successfully connected to the server through a modem. This mode allows running of DOS-based programs that are stored on the service partition and transferring of files. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 55: Running The Dpc Console

    V6.22 operating system. It may run on other ROM-DOS- compatible operating systems but they are not supported. The SSU will not operate from a “DOS box” running under an operating system such as Windows. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 56: System Setup Utility Main Window

    5. This message appears: Please wait while the Application Framework loads..6. When the main window of the SSU appears, you can customize your interface before continuing. (See Figure 24.) Figure 24. System Setup Utility Main Window MAXDATA PLATINUM Server Board User’s Manual...

  • Page 57: Customizing The Ssu

    • Highlight the task name, and click on OK. • Use the tab and arrow keys to highlight the desired button, and press the spacebar or <Enter>. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 58: Multiboot Options Add-In

    User Password Button The ‘User Password’ button allows the user to set or change the user password used by both the SSU and the system BIOS. All changes to the user password take place immediately. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 59: Sel Manager Add-In

    The File menu has the following options: • Open: View data from a previously saved SEL file. • Save As: Save the currently loaded SEL data to a file. • Exit: Quits the SEL Viewer. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 60: Fru Manager Add-In

    Output Text/Binary: Determines whether FRU data will be saved to the file (as under File - Save) in binary format or verbose format. Help The Help menu has the following option: • About: Displays the FRU Viewer version information. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 61: Sdr Manager Add-In

    • Verify: Compares the contents of the nonvolatile storage with the selected file. If a file was not selected, the system will prompt you for one. You cannot verify the BIOS. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 62: Configuration Save/Restore Add-In

    NOTE BIOS passwords are stored in the file. Restoring a configuration can make passwords change on a server. • Close: Closes the CSR main window. • Help: Displays help information. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 63: Platform Event Manager Add-In

    Configure EMP: Opens a new dialog that allows you to configure the Emergency Man- agement Port features. • Close: Exits the Platform Event Manager and returns you to the AF . • Help: Displays help information. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 64: Platform Event Paging Dialog

    Enable PEP Checkbox Enable or disable the PEP feature entirely. Blackout Period in Minutes Enter the time, in minutes, between successive pages. The valid range is [0 – 255] where 0 disables the blackout period. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 65: Bmc Lan-Configuration Dialog

    • Help: Displays help information. BMC LAN-Configuration Dialog This dialog allows you to configure the BMC LAN-Configuration features. (See Figure 27 .) Figure 27. BMC LAN-Configuration Dialog MAXDATA PLATINUM Server Board User’s Manual...
  • Page 66 Static: Allows you to set the server host IP address, router IP address and subnet mask. The host IP address, router IP address and subnet mask will be saved if this radio button is checked. The values saved will take effect immediately. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 67: Platform Event Action Dialogs

    Enable global action for events to generate actions. This global flag is in the PEP or BLA dialogs as ‘Enable PEP’ or ‘Enable BLA’ checkboxes. Figure 28. Platform Event Action Dialogs MAXDATA PLATINUM Server Board User’s Manual...

  • Page 68: Emergency Management Port Dialog

    • Help: Displays help information. Emergency Management Port This dialog allows you to configure the Emergency Management Port features. (See Figure 29.) Figure 29. Emergency Management Port Dialog MAXDATA PLATINUM Server Board User’s Manual...
  • Page 69 In Disabled the EMP powers-up deactivated and is not automatically activated by BIOS, power-down or hard resets. Restricted Mode Access When restricted mode is enabled control operations that could disable or alter a running system via the EMP are disabled. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 70: Exiting The Ssu

    Event Actions from the Options menu. This will bring up the Platform Event Action dialog. 7 . Save all the changes made by clicking on the Save button. Saving writes your current configuration to nonvolatile storage where it will be available to the system after every reboot. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 71: Software Updates

    4. Make the diskettes DOS bootable. 5. Record the current BIOS settings. a. Boot the computer and press <F2> when you see the splash screen. b. Write down the current settings in the BIOS Setup program. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 72: Extraction

    Serial Number, Part Number, and Asset Tag. Following the update process, the system will automatically reboot. Upon completion, it may be necessary to enter BIOS setup and reconfigure the setting values. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 73: Individual Updates

    7 . To extract the BIOS.EXE file to the diskette, change to the temporary directory that holds the BIOS.EXE file and type: BIOS A: 8. Press <Enter>. 9. The diskette now holds the BIOS upgrade and recovery files. MAXDATA PLATINUM Server Board User’s Manual...
  • Page 74 Changing the BIOS Language You can use the BIOS upgrade utility to change the language BIOS displays. Use a bootable ® diskette containing the Intel flash utility and language files. See “Using BIOS Setup” on page 41. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 75: Firmware Update Utility Description

    README.TXT file. If the diskette drive is disabled, or improperly configured, use BIOS Setup to enable it. If necessary, disable the drive after you are done with the FRU/SDR utility. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 76: Command Line Format

    DOS-accepted, eight-character filename string. The utility loads the specified CFG file and uses the entries in that file to probe the hardware and to select the proper SDRs to load into nonvolatile storage. MAXDATA PLATINUM Server Board User’s Manual...
  • Page 77 The chassis area reads out of the specified .FRU file. Finally, it reads the product area out of the specified FRU file, then the area programs into the FRU nonvolatile storage. All areas write to the FRU.TMP file. MAXDATA PLATINUM Server Board User’s Manual...
  • Page 78 MAXDATA PLATINUM Server Board User’s Manual...

  • Page 79: Solving Problems

    Is AC power available at the wall outlet? Are all integrated components from the tested components lists? Check the tested memory, and chassis lists, as well as the supported hardware and operating system list ® on the Intel Customer Support website. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 80: Running New Application Software

    If you are experiencing any of the above symptoms that might indicate voltage spikes on the power line, you may want to install a surge suppressor between the power outlet and the system power cord. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 81: More Problem Solving Procedures

    Once the system boots up, the operating system prompt appears on the screen. The prompt varies according to the operating system. If the operating system prompt does not appear, see “Initial System Startup” on page 79. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 82: Specific Problems And Corrective Actions

    4. If you do not receive a beep code and characters do not appear, the video display monitor or video controller may have failed. Contact your service representative or authorized dealer for help. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 83: Characters Are Distorted Or Incorrect

    “Onboard Floppy” is set to “Disabled. ” If the problem persists, there may be a problem with the diskette drive, server board, or drive signal cable. Contact your service representative or authorized dealer for help. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 84: Cd-Rom Drive Activity Light Does Not Light

    The add-in adapter stopped working without apparent cause: Try reseating the adapter first; then try a different slot if necessary. The network driver files may be corrupt or deleted. Delete and then reinstall the drivers. Run the diagnostics. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 85: Problems With Application Software

    Is the BIOS set to allow the CD-ROM to be the first bootable device? Check cable connections. Verify CD is bootable in another known good CD-ROM drive. (Especially if the CD is a copy.) MAXDATA PLATINUM Server Board User’s Manual...
  • Page 86 MAXDATA PLATINUM Server Board User’s Manual...

  • Page 87: Technical Reference

    If these pins are jumpered, the CMOS password is cleared. These pins should not be jumpered for normal operation. RCVRY BOOT If these pins are jumpered, the system will attempt BIOS recovery. These pins should not be jumpered for normal operation. MAXDATA PLATINUM Server Board User’s Manual...

  • Page 88: Diagnostic Leds

    Keyboard Init: The keyboard controller command byte is written. Next, issuing the pin 23 and 24 blocking and unblocking com mands Disable and initialize 8259 Detect Configuration Mode, such as CMOS clear. Chipset Initialization before CMOS initialization continued MAXDATA PLATINUM Server Board User’s Manual...
  • Page 89 Initialize language module. Display splash logo. Display Sign on message, BIOS ID and processor information. Detect USB Mouse: Initializing the bus input, and general devices next, if present. Reset IDE Controllers continued MAXDATA PLATINUM Server Board User’s Manual...
  • Page 90 Lock out PS/2 keyboard/mouse if unattended start is enabled. Option ROM Scan Init Boot Devices: The adapter ROM had control and has now returned control to BIOS POST. Performing any required processing after the option ROM returned control. continued MAXDATA PLATINUM Server Board User’s Manual...
  • Page 91 Copy required language strings to shadow RAM. Clear video screen. 000h One Beep to indicate end of POST. No beep if silent boot is enabled. 000h POST completed. Passing control to INT 19h boot loader next. MAXDATA PLATINUM Server Board User’s Manual...
  • Page 92 MAXDATA PLATINUM Server Board User’s Manual...

  • Page 93: Regulatory And Integration Information

    This product has been tested in accordance too, and complies with the Low Voltage Direc- tive (73/23/EEC) and EMC Directive (89/336/EEC). The product has been marked with the CE Mark to illustrate its compliance. MAXDATA PLATINUM Server Board User’s Manual...
