System Management
Web-based administration
SNMP v1/v2c
Provides Event Log
Syslog information support
Statistics
Configuration backup and restore
One-button-click to restore factory default setting
Firmware upgrade
Capable of performing RADIUS Accounting and Accounting Update
Security
WEP (64/128/152 bits)
EAP-TLS + Dynamic WEP
EAP-TTLS + Dynamic WEP
PEAP / MS-PEAP + Dynamic WEP
WPA (PSK + TKIP)
WPA (802.1X certification + TKIP)
802.11i WPA2 (PSK + CCMP / AES)
802.11i WPA2 (802.1X certification + CCMP / AES)
Setting for TKIP / CCMP / AES key's refreshing period
Hidden ESSID support
MAC Address filtering (MAC ACL)
MAC authentication with RADIUS servers
Maximum number of registered RADIUS servers: 2
Built-in Servers & Client Interfaces to Other Services
DHCP client
DNS client
Syslog client
RADIUS client
SNMP v1/v2c read & write client
Physical and Power
Form factor: In-Wall type
Dimensions (W x H x D):
Center unit: 1.88" x 3.07" x 3.07" (48mm x 78 mm x 78 mm)
Faceplate: 2.95" x 4.72" x 0.35" (75mm x 120 mm x 9 mm)
Weight: 0.42 lbs (0.19 kg)
PoE port: IEEE 802.3af
Power adaptor (Optional, not included in the package):
AC Input: 100~240 VAC, 50~60 Hz
DC Output: 12VDC, 1.5A
Connectors and Display
LAN Port: 1 × 10/100 Base-T Ethernet
NP727 User's Manual V1.00
