1.3 Deployment Topology Diagram

This above deployment scenario illustrates a deployment example.

Hidden in-the-wall behind faceplate, blending into most interior/architectural designs.

Keep the style of a simple LAN wall jack while being able to serve both LAN and WLAN devices.

When managed under a NetComm Internet Access Controller, the combination has been pre-integrated to

provide solutions for many applications.

Represents essential steps, actions, or messages that should not be ignored.

Note:

Contains related information that corresponds to a topic.

Indicates that clicking this button will save the changes you made, but you must reboot the

system upon the completion of all configuration settings for the changes to take effect.

Indicates that clicking this button will clear what you have set before the settings are

applied.

NP727 User's Manual V1.00
