3. Installation
3.1 Panel Function Description
On the front panel of the NP727, there are three LEDs that are used to indicate the POWER status, the WLAN
status, and the link status of the LAN port. On the front panel, there are: one RESET button and one LAN port. The
antenna is built-in chip antenna.
Front Panel
1.
RESET Button:
Press the button to restart the system.
Press the button for more than 30 seconds to reset the system to default settings.
2.
LAN:
The LAN port is for connection with wired networks.
LED status indication:
3.
LAN
OFF indicates no connection; ON indicates connection; BLINKING indicates transmitting data.
4.
WLAN
Green LED ON indicates system ready.
5.
Power
Green LED On indicates power on; OFF indicates power off.
NP727 User's Manual V1.00
