4.5.3 Repeater Information
The administrator can review detailed information of the repeater function on this page. Information of
repeater's status, mode and encryption is provided
•
Repeater Status: The table will be displayed when Repeater mode is selected.
Status: The status of the repeater function either Enabled or Disabled.
Mode: The mode selected for the repeater function, either Universal Repeater or WDS.
Encryption: The encryption type used: None, WEP, or WPA-PSK.
•
WDS Link Status: The table will be displayed when WDS mode is selected. For more information on the
repeater type, please refer to Section 4.2.5 Repeater Settings.
MAC Address: The MAC Address of the WDS peer.
RSSI: Received Signal Strength Indication, a measurement of received radio signal over WDS link.
Tx Rate: The transmit rate of the Repeater.
Tx Count: The accumulative number of transmission counts.
Tx Error: The accumulative number of transmission errors.
< Fig. 4.5.3-1 Repeater Information: WDS Page>
