Digital Video Quad Processor
Figure 2.2 Typical Installation Configuration for LTC 2382/90
1
2
3
2.3.1
LTC 2380/90 Rear Panel Connections
The figure below illustrates the rear panel connectors for the LTC 2380/90 video processor.
Figure 2.3 LTC 2380/90 Rear Panel
Video Inputs/Outputs
IN 1
IN 2
IN 3
IN 4
OUT 1
OUT 2
OUT 3
OUT 4
MON
Power
5V DC
GND
Bosch Security Systems, Inc.
IN
1
1
ALM/RS-232
OUT
GND
2
1
6
RS232 to PC
Alarm In (pins 1 to 5, typical alarm)
Auto Terminating Video Loop Outputs
GND
Video Input 1 - BNC 75 Ohm, auto terminating
Video Input 2 - BNC 75 Ohm, auto terminating
Video Input 3 - BNC 75 Ohm, auto terminating
Video Input 4 - BNC 75 Ohm, auto terminating
Video Loop Output 1 - BNC
Video Loop Output 2 - BNC
Video Loop Output 3 - BNC
Video Loop Output 4 - BNC
Monitor Output Video - BNC 75 Ohm output impedance
2.0 mm DC Power Jack (outside diameter: 6.4 mm, pin diameter: 2.0 mm
Screw to connect an external earth wire
PLAY IN
3
2
4
MON
MON
2
3
4
REC OUT
3
4 5
4
PLAY IN
5
REC OUT (record out)
6
VCR or DVR
IN
1
2
3
4
1
2
3
4
OUT
User's Guide
Unpacking | en
5V DC
MON
MON
5V DC
F.01U.090.110 | 3.0 | 2010.04
11
