Page 1: User Manual
User Manual MDHB Series 1U High Brightness LCD Drawer Options : - BNC / HDMI / Audio - Touch-Screen / DC Power Designed/Manufactured by Austin Hughes and Distributed by Eclipse Rackmount, Inc. Manual ML30V02A -- Generation 4 -- www.EclipseRackmount.com... -
Page 2: Legal Information
Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment. -
Page 3: Table Of Contents
Contents < Part. 1 > MDHB-17 / MDHB-19 Package Contents Structure Diagram & Dimensions P.1 - 2 Installation < Part. 2 > Specifications / OSD Product Specifications P.4 - 5 On-Screen Display Operation ( OSD ) P.6 - 7 < Part. 3 > Options HDMI, S-Video + BNC &... -
Page 4: Before Installation
Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content. -
Page 5: Package Contents
< Part 1 > < 1.1 > Package Contents MDHB-17 / 19 MDHB-17 or MDHB-19 unit X 1 - 6ft VGA cable X 1 - Power cord X 1 - M6 screw, cage nut & cup washer X 8 The above package content is only for the base models ( VGA and DVI-D only ). It varies with options such as HDMI, AV, audio, touch-screen &... - Page 6 < 1.2 > Dimensions Front View UNIT : mm Side View 1mm = 0.03937 inch Top View Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight 441.6 x 500 x 44 mm 590 x 687 x 120 mm 10.5 kg 16.5 kg...
-
Page 7: Installation
< 1.3 > Installation - How to install Installation Slides MDHB-17 / 19 Step ■ Insert the left and right rear mounting brackets into the display drawer. Step ■ Measure the depth of the front and rear mounting rails. ■ Align each rear mounting bracket to a suitable length. -
Page 8: Product Specifications
< Part 2 > < 2.1 > Product Specifications MDHB-17 MDHB-19 Panel Panel Size ( diagonal ) 17-inch TFT color LCD 19-inch TFT color LCD Display pixel ( dots x lines ) 1280 x 1024 1280 x 1024 Brightness ( typ. ) 1000 1000 Contrast Ratio ( typ. - Page 9 MDHB-17 / 19 Environmental Operating Temperature 0 to 50°C degree Conditions Humidity 20~90%, non-condensing Storage Temperature -5 to 60°C degree Humidity 5~90%, non-condensing Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random MDHB-17 MDHB-19 Physical Specification Product ( W x D x H ) 441.6 x 500 x 44 mm 441.6 x 500 x 44 mm 17.4 x 18.9 x 1.73 inch...
-
Page 10: On-Screen Display Operation ( Osd )
< 2.3 > On-Screen Display Operation ( OSD ) Membrane Switch Function Turn the monitor on or off Display the OSD menu Act as an Enter key to select screen setting options Scroll through menu options and adjust the displayed control Exit the OSD screen Go back to the previous on-screen sub-menu or main menu... - Page 11 < 2.3 > On-Screen Display Operation ( OSD ) MDHB-17 / 19 OSD Conf guration Page Image: for the brightness, contrast, color temp, red, green, and blue Geometry: for the auto adjust, H position, V position, phase and clock Video: for the colour, tint, sharpness, noise reduction, DCDi and TV Setup Audio: for volume, bass, treble, balance, AVL and mute...
-
Page 12: Part. 3 > Options
< Part 3 > < 3.1 > Options : - HDMI ( HDMI 1.1, CEA-861-D ) - BNC ( S-Video + Composite, BNC ) - Audio ( 3.5mm audio jacks for audio in & out, and 2W + 2W speakers ) ( 1 ) Either HDMI or DVI-D can be selected. - Page 13 < 3.2 > Options : Touch-Screen & Driver MDHB-17 / 19 17” / 19" USB Touch-Screen Specif cation 17’ 19” 17” 19” Model e-Resistive e-Capacitive Technology 5-Wire Resistive Capacitive Touch Point Single Single Method Stylus or Finger Finger Activation Force ≤...
- Page 14 < 3.3 > Options : DC Power Model Input rating Input voltage: 24-Volt 48-Volt Input range: 18 ~ 36V 36 ~ 75V Input current - No load 50 mA 50 mA - Full load 4880 mA 2442 mA Output rating Output voltage: 12-Volt 12-Volt...
- Page 15 The company reserves the right to modify product specif cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2013 Austin Hughes Electronics Ltd. & Eclipse Rackmount, Inc. All rights reserved. Manual ML30V02A -- www.EclipseRackmount.com...
