8. If the processor is not being replaced, install a processor baffle
processor baffle" (page
CAUTION:
install a processor baffle in an empty processor socket.
To replace a processor that is not defective, reverse the removal procedure.
The replacement processor module is shipped from HP without a heat sink. You will need to order
and attach a heat sink to the processor module before installing them for repair.
For more information on the installation procedure, see
module" (page 51)
IMPORTANT:
DO NOT SEPARATE THE PROCESSOR FROM THE HEAT SINK FOR A DEFECTIVE MATERIAL
RETURN. The heat sink and processor must be returned as a unit to facilitate testing and root
cause analysis.
Do not discard your heat sink packaging or processor ESD bag. Reuse this packaging to
return any exchange material.
You MUST use a new heat sink with an undisturbed thermal interface for processor installation.
To receive credit for returning defective material, make sure to include the processor paperwork.
NOTE: After replacing the processor and heat sink module use the cpuconfig from UEFI to
verify the that the processor socket has been reconfigured.
HP Confidential
116)).
To avoid damage to processor socket pins and ensure proper system cooling,
.
"Installing a processor and heat sink
Removing and replacing a processor and heat sink module
("Removing and replacing the
1 19
