1.1 Introduction

The UTC-520 is an Intel low-power Intel® Atom
designed to serve as a interactive self-service terminal and as a multimedia com-
puter. It is a PC-based system with 21.5" TFT LCD display, on-board PCIe Ethernet
controller, one COM port and A VGA connector. With a built in internal IDE connector
(for CF card), one SATA connector for HDD and an mini PCIe expansion socket, the
UTC-520 is a compact and user-friendly multi-function computer. In addition, its "fit
anywhere" design makes it very flexible and able to be used in many different kinds
of installations. It can be wall mounted or stood upright on a desktop.
For system integrators, this simple, complete, compact and highly integrated multi-
media system lets you easily build UTC-520 into your applications. Common indus-
trial applications include self-transaction & healthcare, information kiosk & interactive
signage. UTC-520 is a reliable, cost-effective solution for your application require-
ments.

1.2 General Specifications

1.2.1 General

Dimensions (W x H x D): 516 x 313 x 40 mm
Weight: 6 kg
Power supply: ATX type Input Voltage: +12 V
Power adaptor: AC/DC (Standard Build in)
Input voltage:100 ~ 240 V
Output voltage: 12 V @ 5 A
Disk drive housing: Space for one 2.5" SATA HDD
Front panel: IP54/NEMA4 compliant

1.2.2 Standard PC functions

CPU: Onboard Intel® Atom
BIOS: AMI 16 Mbit flash BIOS
System chipset: Intel® Atom
2nd level cache: 512 KB x 2
System memory: One 200-pin SO-DIMM socket, accepting up to 2GB DDR2
667 (doesn't support DDR2 533MHz Memory) Function
Serial ports: 1* external COM
Universal serial bus (USB) port: Supports up to 2 USB V2.0
Mini PCI-E bus expansion slot: Accepts one mini PCI-E device(Wire less LAN
card)
Solid State Disk: Supports CompactFlash card type I/II (True IDE mode)
Watchdog timer: Single chip Watchdog 255-level interval timer, setup by soft-
ware
Power management: Full ACPI (Advanced Configuration andPower Interface)
2.0 Supports S0, S1, S3,S4, S5

1.2.3 VGA Interface

Chipset: The GPU Contains a refresh of the third generation graphics core
Memory Size: Up to 224 MB of dynamic video memory allocation
Interface: VGA
Display mode:
– CRT: Analog RGB display output resolution up to 2048*1536 @ 60 Hz
