INTRODUCTION OVERVIEW OpenEye’s CM-650 is a 5 megapixel box camera designed for indoor installations where high resolution images are required. The CM-650 transmits images across the network using MJPEG and H.264 codecs and offers dual and quad streaming capabilities as well as high-resolution analog output.
Before proceeding, please check that the box contains the items listed here. If any item is missing or has defects, DO NOT install or operate the product and contact your dealer for assistance. CM-650 Adjustment Tool Quick Start Guide 31100AC...
CAMERA OVERVIEW Before installing or connecting the camera, please refer to this section and complete preparations for setup and all switch settings. Dimensions • Length – 5 inches (125 mm) • Width – 3.25 inches (82 mm) • Height – 2.08 inches (53 mm)
Connections Alarm I/O Video Network Auto Iris Line out, Line in / Mic Out Reset Micro SD card slot Power LED Power Item Definition Video Connector Analog Video Output Alarm I/O Output + Output - Input + Input 1 Power Connection 12V Power Reset Button Reset to factory default...
Read the installation instructions before installing and connecting the IP camera. Power Connection You can use 12vDC power or Power over Ethernet (PoE) to power the CM-650 camera. When powered by PoE, any 802.3af compliant device may be used to provide power.
Once the lens is attached, remove the lens cap. ALARM I/O CONNECTION The CM-650 is equipped with one alarm input and one relay output. Refer to alarm pin definition below to connect alarm devices to the IP camera if needed.
LOCATE CAMERA OPENEYE NETWORK CAMERA MANAGER Use the included Network Camera Manager software to easily find your network cameras for initial setup. The OpenEye IP Finder software is included on the CD with all OpenEye IP devices. Installation You can install Network Camera Manager on any personal computer (PC) or laptop using the software CD included with your OpenEye IP camera or by downloading the program from openeye.net.
Device Addressing The functions on the Device Addressing tab allow you to find, configure, and view network cameras. Finding Network Devices Click Find Devices on the Device Addressing tab. To narrow your search by Camera Model, Project, or Camera Name, select your desired criteria from the appropriate lists.
OpenEye IP cameras using third party software like VLC media player (http://www.videolan.org). To connect the camera you may need to provide the stream URL. All OpenEye IP cameras are capable of delivering two RTSP streams, as well as streaming MJPEG over HTTP.
There are some challenges with connecting to OpenEye IP cameras over WAN (internet) connections because the camera streams video over RTSP. RTSP is an excellent protocol for media and is now used on many IP cameras (including OpenEye) as the default streaming option.
ActiveX controls and plug-in settings. For additional information on adjusting the settings of your Internet Explorer browser contact your system administrator or refer to FAQ #1914 at openeye.net If your internet browser asks for permission to install the ActiveX control, you must allow the ActiveX control to continue the installation.
Home Screen Size Adjustment – Click the screen size buttons to adjust image display size x1/2 and full screen. Digital Zoom Control – In full screen mode, right-click to activate digital zoom and use the scroll wheel to zoom in/out. Talk –...
System Note The System tab is only accessible by the Administrator. System Host Name – The Host Name is used to identify the camera on your system. If camera based Motion Detection is enabled and is set to send alarm message by Mail/FTP, the host name entered here will display in the alarm message.
Security Admin Password To change the administrator password, type a new password in the Admin Password box and confirm below. Note The maximum length of the password is 14 characters. The following characters are valid: A-Z, a-z, 0-9, !#$%&’-.@^_~.
Add User The user name and passwords are limited to 16 characters. There is a maximum of twenty user accounts Type the new User name and Password Select the appropriate check boxes to give the user Camera Control, Talk and Listen permissions.
Every network device has a unique Media Access Control (MAC) address that can be used for identification. The MAC address is located on the bottom of each camera, and on the box label (the OpenEye IP Finder also displays the MAC address for identification). Record your camera’s MAC address for identification in the future.
Page 27
When using static IP address to log in to the IP Camera, you can access it either through OpenEye IP Finder software or type the IP address directly in the Address bar of your internet browser. General • IP address – The IP Address is necessary for network identification.
DDNS DDNS (Dynamic Domain Name Service) is a service that allows a connection to an IP address using a hostname (URL) address instead of a numeric IP address. Most Internet Service Providers use Dynamic IP Addressing that frequently changes the public IP address of your internet connection;...
Mail The camera can send an e-mail via Simple Mail Transfer Protocol (SMTP) when motion is detected or when the sensor input is activated. SMTP is a protocol for sending e-mail messages between servers. SMTP is a relatively simple, text-based protocol, where one or more recipients of a message are specified and the message text is transferred.
The camera can send alarm message to a specific File Transfer Protocol (FTP) site when motion is detected or when the sensor input is activated. You can assign alarm message to up to two FTP sites. Enter the FTP details, which include server, server port, user name, password and remote folder, in the appropriate boxes.
Application The CM-650 is equipped with one alarm input and one relay output to connect to an alarm system to catch event images. Refer to Camera Overview > Connections to connect alarm devices to the IP Camera if needed. Alarm Switch – Enable or disable the alarm function.
Page 32
• Upload Image by E-Mail – Select to assign an e-mail address. When the alarm is triggered, event images will be sent to the configured e-mail address. Note Make sure SMTP or FTP configuration has been completed. See the Mail and FTP section of this manual for further details.
Motion Detection Motion Detection allows the camera to detect motion and trigger alarms when motion in the detected area exceeds the determined sensitivity threshold value. In the Motion Detection page, there is a motion detection window (red box) displayed on the Live View Pane.
Page 34
When motion detection is activated, the Motion pop-up window will open. When motion is detected, the signals will be displayed on the Motion window as shown below. Motion Detection Turn motion detection on or off. The default setting is Off. Motion Detection Setting •...
Page 35
Triggered Action You can specify which actions the camera should take when motion is detected. • Enable Alarm Output – This will activate the camera’s alarm output. • Send Alarm Message by FTP/E-Mail – Select to send an alarm message to a configured FTP server and/or e-mail address when motion is detected.
Page 36
File Name – Enter a file name in the box, ex. image.jpg. The uploaded image’s file name format can be set in this section. Please select the one that meets your requirements. • Add date/time suffix File name: imageYYMMDD_HHNNSS_XX.jpg Y: Year, M: Month, D: Day H: Hour, N: Minute, S: Second X: Sequence Number •...
Storage Management The CM-650 has an integrated microSD™ card that can be used to record video or images. The card slot is compatible with a microSD™ card up to 4GB. Device Information – Displays the storage total size and free space information of the included microSD™...
Recording The recording schedule allows you to set up scheduled recording to the microSD™ card. Recording Schedule – The camera can be set up to record continuously until the card is full (or overwrite old data, see the Storage Management section). The camera can also be set up to record only during a scheduled time.
Snapshot The camera supports a JPEG snapshot function. You can specify a storage location for the snapshot images. The default location is: C:\. Note If you are using Windows Vista or 7, you will need to change the Snapshot location. Windows UAC does not allow internet programs to write directly to C:\ for security reasons.
Information The Information page contains the camera’s System Log, User Information and Parameter List. System Log Click System Log to view the system log file. The content of the file provides useful information about configuration and connections.
View User Information The Administrator can view each user’s login information and privileges on the View User Information page. All users for the camera are listed under User information. The example below show that the Admin password is 1234 and there is one user named User with the password 4321. View User Privilege Select a user account from the list and click get user privacy to view the permissions for the user account.
Software Upgrade Upgrading the Camera Viewer Software Note Make sure the new firmware file is available before starting a software upgrade. Click Browse and select the firmware file. Note Do not change the file name, or the system will not be able to update to the new firmware.
Page 44
When the upgrade process is complete the viewer will return to the Home page. After updating it is important to make sure the camera viewer software is updated: Close your browser. Go to the Windows Control Panel and double-click Add or Remove Programs. Locate the Camera Viewer software on the Currently installed programs list, and click Remove to uninstall the previous software version.
Maintenance On the Maintenance page you can export the cameras current configuration, or import the configuration for a camera. Note Do not import configuration files from different models of cameras. Set Default –To reset the IP camera to the factory default settings, including the default IP address, click Set Default.
Video and Audio Streaming Settings On the Streaming tab, you can configure specific video resolution, video compression mode, video protocol and audio transmission mode. Video Format Select the desired video resolution for the camera on the Video Format page. Recording will be based on the resolution selected here.
Video Rotate Type You can change the orientation of the video output if necessary. • Normal transmits the image as the camera sees it. • Flip transmits the image upside down and mirrored. • Mirror transmits a mirror image. • 180 degree transmits the image upside down.
Video Compression You can select an MJPEG/H.264 compression mode on the video compression page appropriate for your application. You can also select to display compression information on the Home page. MJPEG compression settings include: • high compression, low bitrate, low quality •...
Video OCX Protocol On the Video OCX protocol page, you can select different protocols for streaming media over the network. In the case of multicast networking, you can select the Multicast mode. Video OCX protocol setting options include: • RTP over UDP •...
Frame Rate Control Setting the camera to transmit fewer frames can save bandwidth. Use the Frame Rate Control to adjust the camera’s frame settings if necessary. Each of the MJPEG and H.264 streams can have a separate frame rate setting from 1 to 30 frames per second Note When set to 1920 x 1080, the max frame rate decreases to 15 frames...
Video Mask You can use the video mask page to define a privacy mask to keep users from viewing parts of the image. You can add two privacy masks and choose a color to obscure the live view from users. 31100AC...
Audio On the Audio page, the Administrator can select an audio transmission mode and audio bit rate. Note Audio monitoring and recording laws vary from location to location. It is highly recommended that you consult your local, state and federal laws to verify that you are in compliance before implementing audio recording.
Bit Rate Selectable audio transmission bit rate include: 16 kbps (G.726) 24 kbps (G.726) 32 kbps (G.726) 40 kbps (G.726) uLAW (G.711) ALAW (G.711). Both uLAW and ALAW signify 64 kbps but in different compression formats. Higher bit rate will provide higher audio quality and require more bandwidth. 31100AC...
Camera Exposure The exposure is the amount of light received by the image sensor and is determined by the width of lens diaphragm opening (iris adjustment), the amount of exposure by the sensor (shutter speed) and other exposure parameters. Full Auto Mode •...
White Balance A camera needs to find reference color temperature, which is a way of measuring the quality of a light source, for calculating all the other colors. The unit for measuring this ratio is in degree Kelvin (K). Users can select one of the White Balance Control modes according to the operating environment.
Saturation Adjust the saturation of color components in the image through the Saturation function, which is adjustable from -6 ~ +19. Adjust the color hue from -12 ~ +12 Backlight Adjust the brightness in an image to compensate for bright light sources. Digital Zoom Zoom in to the center of the image.
IP SPECIFICATIONS Model CM-650 Video Compression H.264 / MJPEG Dual Streaming H.264 + MJPEG, H.264+H.264 Audio In Audio Out Alarm In Alarm Out User Account...
APPENDIX A BACK FOCUS ADJUSTMENT Back Focus refers to the distance from the rear lens element to the focal plane of the camera. In most cases, adjusting back focus is only required when the lens cannot hold focus through the full zoom range. Adjusting Back Focus Set the camera on a stable mount with the test chart or object at least 75 feet (23 meters) away (or as far as possible).
APPENDIX B SET UP INTERNET SECURITY If the installation of ActiveX Control is blocked, you will need to either set the Internet Security Level to the default setting, or change the ActiveX controls and plug-ins setting. Setting Internet Security Level to Default Open Internet Explorer.
Adjusting ActiveX Controls and Plug-ins Open Internet Explorer. Click the Tools tab in the menu bar. Click Internet Options. Click Custom Level. The Security Settings window will pop up. Under ActiveX Controls and Plug Ins, set all items to Enable or Prompt. Items may vary according to your version of Internet Explorer.
