WARNING:! Always remove old or weak batteries. Batteries can leak
!
!
!
!
!
!
!
!
WARNING:! Discontinue use of any battery that exhibits leakage, swelling or
!
!
!

Attaching the antenna

Remove the antenna from its protective plastic wrapper. Align the
slots on the antennaʼs BNC male connector with the posts on the
EZ Scan-SDʼs BNC female connector and slide the antenna in
place, then rotate the antennaʼs BNC connector 1/4 turn
clockwise until it snaps in place.
NOTE: ! If desired, you may also connect a mobile or base station antenna
!

Turning the EZ Scan-SD on

Ensure that the Main Power Off switch on the left side of the EZ
Scan-SD is turned on by gently lifting the switchʼs protective
cover and checking the switch position. Move the Main Power
Off switch to the ON position if necessary.
Press the
on. Set the SQUELCH knob to the mid-point (12 oʼclock)
position.

Battery Charge Indicator

Your EZ Scan-SD provides an indication when the internal
battery charge circuit is active. An animated battery icon
EZ Scan-SD User Manual!
chemicals that destroy electronic circuits. Always turn off the
scanner when not in use to prevent deep discharge and
possible battery leakage. Do not mix old and new batteries,
different types of batteries (alkaline, or rechargeable),
rechargeable batteries of different capacities or rechargeable
batteries with different charge states. If you do not plan to use
the scanner with batteries for a month or longer, remove the
batteries.
abnormal generation of heat. When you charge rechargeable
batteries, do not over charge them. Overcharging shortens
battery life and may cause battery failure.
equipped with a BNC male connector to the antenna connector
button on the front panel to turn the EZ Scan-SD
Page 24
