Recommended transmission ranges at 60 Hz,
TP R BNC A and TP R BNC AV

Video format

Component, S-video, Composite
video and audio
640 x 480
800 x 600
1024 x 768
1280 x 960
1280 x 1024
1360 x 765
1365 x 768
1366 x 768
1440 x 900
1400 x 1050
1600 x 1200
1920 x 1200
The TP receivers only receive signals transmitted by Extron
TP transmitters. This user manual documents installation,
features, and operation of the TP receivers only. For information
about the TP transmitters, refer to the TP Transmitters Family
User's Manual, TP T 15HD 45 and TP T A 45 Manual, or the
VTT001/TR001 Transmitter and Receiver Manual, as applicable,
which accompany the transmitters.
Maximum range
(High Quality)
1000 feet (304 m)
1000 feet (304 m)
800 feet (243 m)
600 feet (182 m)
450 feet (137 m)
400 feet (120 m)
400 feet (120 m)
400 feet (120 m)
400 feet (120 m)
350 feet (106 m)
350 feet (106 m)
300 feet (90 m)
300 feet (90 m)
TP Receivers • Introduction
Maximum range
(Variable Quality)
1050 feet (320 m)
1050 feet (320 m)
900 feet (274 m)
700 feet (213 m)
600 feet (182 m)
500 feet (152 m)
500 feet (152 m)
500 feet (152 m)
500 feet (152 m)
450 feet (137 m)
450 feet (137 m)
400 feet (120 m)
400 feet (120 m)
1-3
