Extron Electronics, USA
Extron Electronics, Europe
1230 South Lewis Street
Beeldschermweg 6C
Anaheim, CA 92805
3821 AH Amersfoort
USA
The Netherlands
714.491.1500
+31.33.453.4040
www.extron.com
Fax 714.491.1517
Fax +31.33.453.4050
© 2003 Extron Electronics. All rights reserved.
Extron Electronics, Asia
Extron Electronics, Japan
135 Joo Seng Road, #04-01
Daisan DMJ Building 6F
PM Industrial Building
3-9-1 Kudan Minami
Singapore 368363
Chiyoda-ku, Tokyo 102-0074 Japan
+65.6383.4400
+81.3.3511.7655
Fax +65.6383.4664
Fax +81.3.3511.7656
User's Manual
Do not connect this device to a computer data or
CAUTION
telecommunications network
HIgh Resolution Video, Composite Video, and Stereo Audio
Twisted Pair Cable Transmission Products
TP Receivers Family
68-547-02 Rev. G
Printed in the USA
08 03
Advertisement
Table of Contents
Related Manuals for Extron electronics TP R AV
Summary of Contents for Extron electronics TP R AV
- Page 1 Extron Electronics, USA Extron Electronics, Europe Extron Electronics, Asia 1230 South Lewis Street Beeldschermweg 6C 135 Joo Seng Road, #04-01 Anaheim, CA 92805 3821 AH Amersfoort PM Industrial Building Singapore 368363 The Netherlands 714.491.1500 +31.33.453.4040 +65.6383.4400 www.extron.com Fax 714.491.1517 Fax +31.33.453.4050 Fax +65.6383.4664 ©...
-
Page 2: Part Numbers
Precautions Safety Instructions • English Warning This symbol is intended to alert the user of important Power sources • This equipment should be operated only from the power source indicated on the product. This equipment is intended to be used with a main operating and maintenance (servicing) instructions power system with a grounded (neutral) conductor. -
Page 3: Table Of Contents
Features ... 1-3 TP R BNC A receiver ... 1-3 TP R BNC AV receiver ... 1-4 TP R AV receiver ... 1-4 TP R 15HD A receiver ... 1-5 Chapter 2 • Installation and Operation Installation Overview ... 2-2 Video jumpers ... -
Page 4: Chapter 1 • Introduction
Table of Contents, cont’d Appendix • Specifications Accessories, and Part Numbers ... A-1 Specifications ... A-2 Included Parts ... A-5 Accessories ... A-6 Cables /Adapters ... A-6 All trademarks mentioned in this manual are the properties of their respective owners. TP Receivers •... -
Page 5: About The Tp Receivers
(100 to 800 feet). The minimum reliable transmission distance for the TP R BNC A, TP R BNC AV, and TP R AV is 50 feet. The TP R 15HD A provides reliable reception and high quality video output without the minimum distance limitation. -
Page 6: Tp R Bnc Av Receiver
Desk Mounting Kit (part #70-077-01) or Through Desk Mounting Kit (part #70-077-02). TP R AV receiver The TP R AV receiver has the following features: Video output — Provides composite video on one BNC connector. RJ-45 connector — Allows attachment to an Extron TP transmitter. -
Page 7: Chapter 2 • Installation And Operation
Introduction, cont’d TP Receivers This page was intentionally left blank Chapter Two Installation and Operation Installation Overview Front Panel Controls and Indicators Troubleshooting TP Receivers • Introduction... -
Page 8: Installation Overview
See Video jumpers or Video DIP switch in this chapter. TP R BNC AV and TP R AV only — If desired, configure the audio jumpers to make the receiver compatible with unmodified TP transmitters. See Audio jumpers in this chapter. -
Page 9: Video Dip Switch
Redesigned (modified) receivers and transmitters have an identifying label. The TP R BNC AV and TP R AV receivers are factory configured to receive the audio that is associated with the composite video link on wire pair 3 and 6. This configuration is compatible with redesigned TP transmitters and the TPX 88 A. -
Page 10: Mounting The Receiver
TP Receivers • Installation and Operation TP R AV TP R BNC AV W ER V .5A A -V D IO V ID Remove 1 (TP R AV) or 6 (TP R BNC AV) BNC Hex Nuts Wire Pair Wire Pair 3&6* 7&8 Wire Pair Wire Pair 3&6*... -
Page 11: Furniture Mounting
Installation and Operation, cont’d TP R 15HD A only — For optional rack mounting, mount the receiver on a VersaTools 19" 1U Rack Shelf (Extron part #60-190-20) (figure 2-4). The TP R 15HD A mounts in one of four locations on the rack. R 15 VersaTools Rack Shelf R 15... -
Page 12: Projector Mounting
(figure 2-6). Projector Mounting Bracket Mounting Bolt Projector Mounting TP R AV Bracket Figure 2-6 — Projector bracket mounting a receiver 2-10 TP Receivers • Installation and Operation Rear panel features and cabling A-V INPUT RGB INPUT... -
Page 13: Output Cabling
RGBHV video. N/C (TP R 15HD A only) — No connection. Composite video The TP R BNC AV and the TP R AV receive and output composite video. Video connector — Connect a composite video device to this rear panel BNC connector. Digital audio can also be connected to this connector. -
Page 14: Audio
15V power supply. 2-14 TP Receivers • Installation and Operation TP R BNC A and TP R AV — Wire the external 15V power supply into this 3-pole captive screw connector (figure 2-9) and plug the connector into the receiver. -
Page 15: Tp Receivers
Installation and Operation, cont’d Cable testing To ensure proper cable termination, each transmission cable system that uses CAT 5e should be tested (Extron’s Skew-Free UTP cable does not need to be tested). Testing the cable from the RJ-45 connections at the transmitter and receiver gives the most accurate indications of cable problems. -
Page 16: Front Panel Controls And Indicators
Installation and Operation, cont’d Front Panel Controls and Indicators The TP R BNC A and TP R BNC AV have similar controls and indicators (figure 2-12). The TP R 15HD A has a reduced set of controls (figure 2-13). VIDEO MANUAL LEVEL AUTO... -
Page 17: If The Image Is Not Displayed Correctly
Installation and Operation, cont’d For computer video from a laptop or for ungrounded AC distribution systems, the transmitter may need to be grounded. See Grounding the transmitter in the TP Transmitter Family User’s Manual, part #68-546-01. Call the Extron S Sales &... - Page 18 Maximum level (600 ohm) ... >+11.5dBm, balanced at stated %THD+N General Power TP R BNC A, TP R AV ... 15VDC, 0.8 A, external power supply. Product requires 0.3 A (minimum). TP R 15HD A ... 15VDC, 0.8 A, external power supply.
-
Page 19: Included Parts
(4.1 cm H x 10.8 cm W x 7.6 cm D) (Depth excludes connectors.) TP R AV ... 1.25” H x 4.75” W x 7.0” D (3.2 cm H x 12.1 cm W x 17.8 cm D) (Depth excludes connectors.) Product weight TP R BNC A ... -
Page 20: Accessories
Specifications, Accessories, and Part Numbers cont’d Accessories Accessories P/S 150 Multiple output 15V power supply Extron 19" 1U Universal Rack Shelf Extron 19" 1U Basic Rack Shelf Extron VersaTools 19" 1U Universal Rack Shelf Extron VersaTools 19" 1U Basic Rack Shelf Extron Under Desk Mounting Kit Extron Thru-desk Mounting Kit Extron Projector Mounting Kit... - Page 21 Specifications, Accessories, and Part Numbers cont’d This page was intentionally left blank TP Receivers • Specifications, Accessories, and Part Numbers...
