AIMB-564
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIMB-564 and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech AIMB-564

Summary of Contents for Advantech AIMB-564

  • Page 1 AIMB-564 User Manual...

  • Page 2: Copyright Notice

    Copyright Notice The material in this document is the intellectual property of Advantech Co, LTD. We take every care in the preparation of this document, but no guarantee is given as to the correctness of its contents. Our products are under continual improvement and we reserve the right to make changes without notice.

  • Page 3: Federal Communications Commission Statement

    Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including inter- ference that may cause undesired operation.

  • Page 4: Safety Information

    Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may become wet. • Place the product on a stable surface. • If you encounter technical problems with the product, contact a qualified service technician or your retailer. AIMB-564 User Manual...

  • Page 5: About This Guide

    Refer to the following sources for additional information and for product and software updates. Advantech websites For more information on this and other Advantech products, please visit our website at: http://www.advantech.com For technical support and service, please visit our support website at: http://www.advantech.com.tw/support/...
  • Page 6 (+). Example: <Ctrl+Alt+D> Command Means that you must type the command exactly as shown, then supply the required item or value enclosed in brackets. Example: At the DOS prompt, type the com- mand line: afudos /i[filename] AIMB-564 User Manual...
  • Page 7 AIMB-564 Specifications Summary LGA775 socket for Intel® Quad-core / Core™ 2 Extreme/ Core™ 2 Duo / Pentium® D / Pentium® 4 / Celeron® D pro- cessor Compatible with Intel® 05B/05A/06 processors Intel® Hyper- Threading Technology ready Intel® Q965 / ICH8DO with Intel® Active Management Tech-...
  • Page 8 WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE, RPL Support CD Drivers Contents Advantech manual Form uATX form factor: 9.6” x 9.6” (24.4 cm x 24.4 cm) Factor *Specifications are subject to change without notice. AIMB-564 User Manual viii...

  • Page 9: Table Of Contents

    1.4.4 Layout Contents.............. 7 Central Processing Unit (CPU) ......... 9 1.5.1 Installing the CPU............10 Figure 1.4 AIMB-564 CPU socket 775 ....10 1.5.2 Installing the CPU Heatsink and Fan......13 Figure 1.5 AIMB-564 CPU Fan Connector ..... 15 1.5.3 Uninstalling the CPU Heatsink and Fan .......
  • Page 10 Internal Connectors............34 Figure 1.9 Floppy Disk Drive Connector....34 Figure 1.10 SPDIF OUT connector ......34 Figure 1.11 AIMB-564 IDE connector ...... 35 Figure 1.12 SATA connectors ........36 Figure 1.13 IEEE 1394a Connector ......37 Figure 1.14 SATA RAID connector ......38 Figure 1.15 TPM connector ........
  • Page 11 2.4.11 Gate A20 Option............55 2.4.12 Typematic Rate Setting..........55 2.4.13 Typematic Rate (Chars/Sec) ......... 55 2.4.14 Typematic Delay (msec)..........55 2.4.15 Security Option ............. 55 2.4.17 MPS Version Control For OS........56 2.4.18 OS Select For DRAM > 64MB ........56 Advanced Chipset Features..........
  • Page 12 2.11.2 TPM Status [No Change]..........71 Figure 2.15 Security Chip Configuration....72 Figure 2.16 TPM POST Screen ......... 72 2.12 Password Setting ............. 73 2.13 Save & Exit Setup ............74 2.14 Exit Without Saving ............75 AIMB-564 User Manual...

  • Page 13: Product Introduction

    Product Introduction This chapter describes the mother- board features and the new technolo- gies it supports.

  • Page 14: Chapter 1 Product Information

    Thank you for buying an Advantech AIMB-564 motherboard! The motherboard delivers a host of new features and latest technologies, making it another standout in the long line of Advantech motherboards! Before you start installing the motherboard, and hardware devices on it, check the items in your package with the list below.

  • Page 15: Before You Proceed

    1.3 Before you Proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. Caution! 1. Unplug the power cord from the wall socket before touching any component. 2. Use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, before handling components to avoid damaging them due to static electricity.

  • Page 16: Onboard Led

    The illustration below shows the location of the onboard LED. SB_PWR Standby Powered Power Figure 1.1: Onboard LED AIMB-564 User Manual...

  • Page 17: Motherboard Overview

    1.4 Motherboard Overview Before you install the motherboard, study the configuration of your chas- sis to ensure that the motherboard fits into it. Warning! Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so can cause you physical injury and damage motherboard components.

  • Page 18: Motherboard Layout

    CR2032 3V Lithium Cell SATA3 SATA4 CMOS Power PCIEX4_1 AD1988 F_PANEL PRI_EIDE SPDIF_OUT AAFP USB910 CLRTC CHASSIS USB56 USB78 Figure 1.3: Motherboard layout Note: Refer to 1.9 Connectors for more information about rear panel connectors and internal connectors. AIMB-564 User Manual...

  • Page 19: Layout Contents

    1.4.4 Layout Contents Slots Page DDR2 DIMM slots 1-19 PCI slots 1-25 PCI Express x 4 slot 1-25 PCI Express x16 slot 1-26 Jumper Page Clear RTC RAM (3-pin CLRTC) 1-27 Keyboard power (3-pin KBPWR) 1-28 Rear panel connectors Page PS/2 mouse port (green) 1-29 Parallel port...
  • Page 20 CPU_FAN, 3-pin CHA_FAN, 3-pin CHA_FAN2, 3- pin PWR_FAN) Serial port connector (10-1 pin COM1) 1-40 Chassis intrusion connector (4-1 pin CHASSIS) 1-40 Front panel audio connector (10-1 pin AAFP) 1-41 ATX power connectors (24-pin EATXPWR, 4-pin 1-42 EATX12V) AIMB-564 User Manual...

  • Page 21: Central Processing Unit (Cpu)

    1.5 Central Processing Unit (CPU) The motherboard comes with a surface mount LGA775 socket designed for the Intel® Core™2 Extreme/Core™2 Duo/Pentium® D/Pentium® 4 and Celeron® D processors. Note: 1. Make sure the AC power is off before you install the CPU. 2.

  • Page 22: Installing The Cpu

    Installing the CPU To install a CPU: Locate the CPU socket on the motherboard. Figure 1.4: AIMB-564 CPU socket 775 Note: Before installing the CPU, make sure that the cam box is facing towards you and the load lever is on your left.
  • Page 23 Lift the load lever in the direction of the arrow to a 135° angle. Lift the load plate with your thumb and forefinger to a 100° angle (A), then push the PnP cap from the load plate window to remove (B).
  • Page 24 The CPU fits in only one correct orientation. DO NOT force the CPU into the socket to prevent bending the connectors on the socket and damaging the CPU! Close the load plate (A), then push the load lever (B) until it snaps into the retention tab. AIMB-564 User Manual...

  • Page 25: Installing The Cpu Heatsink And Fan

    If installing a dual-core CPU, connect the chassis fan cable to the CHA_FAN1 connector to ensure system stability. Note: The motherboard supports Intel® LGA775 processors with Intel® Enhanced Memory 64 Technology (EM64T), Enhanced Intel SpeedStep® Technology (EIST), and Hyper- Threading Technology. 1.5.2 Installing the CPU Heatsink and Fan The Intel®...
  • Page 26 Orient the heatsink and fan assembly such that the CPU fan cable is closest to the CPU fan connector. Make sure to orient each fastener with the narrow end of the groove pointing outward. (The photo shows the groove shaded for emphasis.) AIMB-564 User Manual...

  • Page 27: Figure 1.5 Aimb-564 Cpu Fan Connector

    Connect the CPU fan cable to the connector on the motherboard labeled CPU_FAN. CPU_FAN Figure 1.5: AIMB-564 CPU Fan Connector Note: Do not forget to connect the CPU fan connector! Hardware monitoring errors can occur if you fail to plug in this connector.

  • Page 28: Uninstalling The Cpu Heatsink And Fan

    Disconnect the CPU fan cable from the connector on the mother- board. Rotate each fastener counterclockwise. Pull up two fasteners at a time in a diagonal sequence to disengage the heatsink and fan assembly from the motherboard. AIMB-564 User Manual...
  • Page 29 Carefully remove the heatsink and fan assembly from the mother- board. Rotate each fastener clockwise to ensure correct orientation when reinstalling. Note: The narrow end of the groove should point outward after resetting. (The photo shows the groove shaded for emphasis.) Chapter 1 Product Information...
  • Page 30 Narrow end of the groove Note: Refer to the documentation in the boxed or stand-alone CPU fan package for detailed information on CPU fan installation. AIMB-564 User Manual...

  • Page 31: System Memory

    1.6 System Memory 1.6.1 Overview The motherboard comes with four Double Data Rate 2 (DDR2) Dual Inline Memory Modules (DIMM) sockets. A DDR2 module has the same physical dimensions as a DDR DIMM but has a 240-pin footprint compared to the 184-pin DDR DIMM. DDR2 DIMMs are notched differently to prevent installation on a DDR DIMM socket.

  • Page 32: Memory Configuration

    4. If you install a Windows® XP 32-bit operating system, a total memory of less than 3GB is recommended. 5. This motherboard does not support memory modules made up of 128 Mb chips or double sided x16 memory modules. AIMB-564 User Manual...

  • Page 33: Installing A Dimm

    Note: Notes on memory limitations: 1. Due to chipset limitations, this motherboard can only support up to 8 GB on the operating sys- tems listed below. You may install a maximum of 2 GB DIMMs on each slot, but only DDR2- 533 and DDR2-667 2 GB density modules are available for this configuration.

  • Page 34: Removing A Dimm

    Note: Support the DIMM lightly with your fin- gers when pressing the retaining clips. The DIMM might get dam- aged if it flips out with extra force. DDR2 DIMM notch 2. Remove the DIMM from the socket. AIMB-564 User Manual...

  • Page 35: Expansion Slots

    1.7 Expansion Slots In the future, you may need to install expansion cards. The following sub- sections describe the slots and the expansion cards that they support. Warning! Make sure to unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components.

  • Page 36: Interrupt Assignments

    Numeric Data Processor Primary IDE Channel Secondary IDE Channel * These IRQs are usually available for ISA or PCI devices. IRQ assignments for this motherboard Table 1.3: IRQ Assignments for AIMB-564 PCI Slot 1 share PCI Slot 2 shared -...
  • Page 37 Table 1.3: IRQ Assignments for AIMB-564 Onboard HD share Audio (AD1988) Onboard GbE- shared - thernet (82566DM) USB 2.0 share EHCI#1 USB 2.0 share EHCI#2 USB12 share UHCI#1 USB34 share UHCI#2 USB56 share UHCI#3 USB78 share UHCI#4 USB910 share UHCI#5...

  • Page 38: Pci Slots

    PCI Express x4 Slot This motherboard supports PCI Express x4 network cards, SCSI cards and other cards that comply with the PCI Express specifications. The fol- lowing figure shows a network card installed on the PCI Express x4 slot. AIMB-564 User Manual...

  • Page 39: Pci Express X16 Slot

    1.7.6 PCI Express x16 Slot This motherboard supports PCI Express x16 graphic cards that comply with the PCI Express specifications. The figure shows a graphics card installed on the PCI Express x16 slot. Chapter 1 Product Information...

  • Page 40: Jumper

    1.8 Jumper 1.8.1 Clear RTC RAM (CLRTC) AIMB-564 User Manual...

  • Page 41: Figure 1.7 Clear Rtc Ram

    This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which include system setup information such as system passwords.

  • Page 42: Keyboard Power (3-Pin Kbpwr)

    (the default is the Space Bar). This fea- ture requires an ATX power supply that can supply at least 1A on the +5VSB lead, and a corresponding setting in the BIOS. KBPWR +5VSB (Default) P5B-VM DO Keyboard Power Setting Figure 1.8: Keyboard Power Setting AIMB-564 User Manual...

  • Page 43: Connectors

    1.9 Connectors 1.9.1 Rear Panel Connectors PS/2 mouse port (green). This port is for a PS/2 mouse. Parallel port. This 25-pin port connects a parallel printer, a scan- ner, or other devices. IEEE 1394a port. This 6-pin IEEE 1394a port provides high-speed connectivity for audio/video devices, storage peripherals, PCs, or portable devices.

  • Page 44: Table 1.5: Audio 2, 4, 6, Or 8-Channel Config

    (USB) ports are available for connecting USB 2.0 devices. USB 2.0 ports 3 and 4. These two 4-pin Universal Serial Bus (USB) ports are available for connecting USB 2.0 devices. VGA port. This port is for a VGA monitor or other VGA-compati- ble devices. AIMB-564 User Manual...
  • Page 45 External SATA port. This port connects to an external Serial ATA hard disk drive. To configure a RAID 0, a RAID 1, or a JBOD set, install and external Serial ATA hard disk drive and an internal Serial ATA hard disk drive to the SATA connector labeled SATA_RAID or SATA_RAID1.

  • Page 46: Internal Connectors

    Connect one end of the S/PDIF audio cable to this connector and the other end to the S/PDIF module. SPDIF_OUT Spdif out P5B-VM DO SPDIF OUT connector Figure 1.10: SPDIF OUT connector Note: The S/PDIF out module is purchased separately. AIMB-564 User Manual...

  • Page 47: Figure 1.11 Aimb-564 Ide Connector

    If any device jumper is set as “Cable-Select,” make sure all other device jumpers have the same setting. PRI_EIDE PIN1 NOTE: Orient the red markings (usually zigzag) on the ID ribbon cable to PIN 1. P5B-VM DO IDE connector Figure 1.11: AIMB-564 IDE connector Chapter 1 Product Information...

  • Page 48: Figure 1.12 Sata Connectors

    Connect the right-angle side of the SATA signal cable to a SATA device. Or you may connect the right-angle side of the SATA cable to the onboard SATA port to avoid mechanical conflict with large graphics cards. AIMB-564 User Manual...

  • Page 49: Figure 1.13 Ieee 1394A Connector

    IEEE 1394a port connector (10-1 pin IE1394_2) This connector is for an IEEE 1394a port. Connect the IEEE 1394a mod- ule cable to this connector, then install the module to a slot opening at the back of the system chassis. IE1394_2 P5B-VM DO IEEE 1394a Connector Figure 1.13: IEEE 1394a Connector...

  • Page 50: Figure 1.14 Sata Raid Connector

    Before creating a RAID set using Serial ATA hard disks, make sure that you have connected the Serial ATA signal cables and installed Serial ATA hard disk drives; otherwise, you can- not enter the JMicron® JMB363 RAID utility and SATA BIOS setup during POST. AIMB-564 User Manual...

  • Page 51: Figure 1.15 Tpm Connector

    TPM connector (20-1 pin TPM_SLOT) This connector supports a Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identi- ties, and ensures platform integrity. See section “2.4.3 TPM Configura- tion”...

  • Page 52: Figure 1.16 Usb 2.0 Connectors

    480 Mbps. USB56 USB78 USB910 Figure 1.16: USB 2.0 connectors Caution! Never connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! Note: The USB module is purchased separately. AIMB-564 User Manual...

  • Page 53: Figure 1.17 Internal Audio Connector

    Optical drive audio connector (4-pin CD) These connectors allow you to receive stereo audio input from sound sources such as a CD-ROM, TV tuner, or MPEG card. (black) Right Audio Channel Ground Ground Left Audio Channel Figure 1.17: Internal Audio Connector CPU, chassis, and power fan connectors (4-pin CPU_FAN, 3- pin CHA_FAN, 3-pin CHA_FAN2, 3-pin PWR_FAN) The fan connectors support cooling fans of 350 mA ~ 2000 mA (24 W...

  • Page 54: Figure 1.19 Serial Port Connector

    By default, the pin labeled “Chassis Signal” and “Ground” are shorted with a jumper cap. Remove the jumper caps only when you intend to use the chassis intrusion detection feature. CHASSIS (Default) Figure 1.20: Chassis Intrusion connector AIMB-564 User Manual...

  • Page 55: Figure 1.21 Front Panel Audio Connector

    Front panel audio connector (10-1 pin AAFP) This connector is for a chassis-mounted front panel audio I/O module that supports either HD Audio or legacy AC’97 audio standard. Connect one end of the front panel audio I/O module cable to this connector. Azalia-compliant Legacy AC 97-compliant pin definition...

  • Page 56: Figure 1.22 Atx Power Connector

    +12 Volts +5 Volts +5V Standby +5 Volts Power OK -5 Volts Ground Ground +5 Volts Ground Ground Ground +5 Volts PSON# Ground Ground +3 Volts -12 Volts +3 Volts +3 Volts Figure 1.22: ATX Power connector AIMB-564 User Manual...
  • Page 57 Note: 1. For a fully configured system, we recommend that you use a power supply unit (PSU) that complies with ATX 12 V Specification 2.0 (or later version) and provides a minimum power of 400 W. 2. Do not forget to connect the 4-pin EATX12V power plug; otherwise, the system will not boot.
  • Page 58 AIMB-564 User Manual...
  • Page 59 Award BIOS Setup...

  • Page 60: Chapter 2 Award Bios Setup

    Using the power button, reset button, or the <Ctrl>+<Alt>+<Del> keys to force a reset from a run- ning operating system can cause damage to your data or system. We recommend to always shut-down the system properly from the operating system. AIMB-564 User Manual...

  • Page 61: Cmos Ram Auto-Backup And Restore

    Note: 1. The default BIOS settings for this motherboard apply for most conditions to ensure optimum performance. If the system becomes unstable after changing any BIOS set- tings, load the default settings to ensure system compati- bility and stability. Select the Load Setup Defaults item under the Exit Menu.

  • Page 62: Figure 2.1 Award Bios Setup Initial Screen

    2.2 Entering Setup Turn on the computer and press <Del> to enter the BIOS setup. Figure 2.1: Award BIOS Setup initial screen AIMB-564 User Manual...

  • Page 63: Figure 2.2 Standard Cmos Features Screen

    2.3 Standard CMOS Setup Figure 2.2: Standard CMOS Features Screen 2.3.1 Date The date format is <weeks>, <months>, <days>, <years>. Chapter 2 Product Information...

  • Page 64: Time

    EGA, VGA, SVGA, or PGA monitor adapters. • CGA 40: Color Graphics Adapter, power up in 40 column mode. • CGA 80: Color Graphics Adapter, power up in 80 column mode. • MONO: Monochrome adapter, includes high resolution monochrome adapters AIMB-564 User Manual...

  • Page 65: Halt On

    2.3.6 Halt On This category determines whether system start-up will halt or not when an error is detected during power up. The options are: No Errors/ All Errors/ All, But Keyboard/ All, But Dis- kette/ All, But Disk/Key 2.3.7 Memory This category displays base memory, extended memory, and total mem- ory detected during POST (Power On Self Test).

  • Page 66: Cpu Features

    The BIOS tries to load the OS from the devices in the sequence set here. The options are: “Floppy”, “LS120”, “Hard disk”, “CDROM”, “ZIP100”, “USB-FDD”, “USB-ZIP”, “USBCDROM”, “USB-HDD”, “LAN”, and “Disabled”. 2.4.7 Boot Other Device Use this to boot another device. The options are “Enabled” and “Dis- abled”. AIMB-564 User Manual...

  • Page 67: Swap Floppy Drive

    2.4.8 Swap Floppy Drive If the system has two floppy drives, choose “Enabled” to assign physical drive B to logical drive A and vice-versa. The commands are “Enabled” or “Disabled”. 2.4.9 Boot Up Floppy Seek Selection of the command “Disabled” will speed the boot up. Selection of “Enabled”...

  • Page 68: Mps Version Control For Os

    81.4 Support MPS Version 1.4. (Default Value) 81.1 Support MPS Version 1.1. 2.4.18 OS Select For DRAM > 64MB Select an operating system that is running with greater than 64MB of RAM on the system. The choices: Non-OS2, OS2. AIMB-564 User Manual...

  • Page 69: Advanced Chipset Features

    2.5 Advanced Chipset Features By choosing the “Advanced Chipset Features” option from the “Initial Setup Screen” menu, the screen below will be displayed. This sample screen contains the manufacturer’s default values for the AIMB-764, as shown in Figure 3.4: Figure 2.4: Advanced Chipset Features screen Note: DRAM default timings have been carefully chosen and should ONLY be changed if data is being lost.

  • Page 70: Configure Amt Bios Support (Intel® Active Manage- Ment Technology)

    The On-Chip Frame Buffer Size can be set to 1 MB or 8 MB. This mem- ory is shared with the system memory. 2.5.5 DVMT Mode Displays the active system memory mode. 2.5.6 DVMT / FIXED Memory Size Specify the size of DVMT / FIXED system memory to allocate for video memory. AIMB-564 User Manual...

  • Page 71: Integrated Peripherals

    2.6 Integrated Peripherals Figure 2.5: Integrated peripherals Figure 2.6: On-Chip IDE Device 2.6.1 On board Lan Boot ROM: Options are “Enabled” and “Disabled”. Select “Disabled” if you don’t want to use the onboard LAN option ROM. Chapter 2 Product Information...

  • Page 72: Ide Hdd Block Mode

    User's Manual on this CD (in the MANUAL folder) to understand the necessary steps to build and configure your RAID 0, 1, 10, 5 system using the Intel® Matrix Storage Tech- nology and Matrix Storage Manager. AIMB-564 User Manual...

  • Page 73: Figure 2.7 Usb Device Setting

    Figure 2.7: USB device setting 2.6.7 USB 1.0 Controller Select “Enabled” if your system contains a Universal Serial Bus (USB) controller and you have USB peripherals. The choices are “Enabled” and “Disabled”. 2.6.8 USB Operation Mode Set the USB 2.0 controller to Hi Speed (480 Mbps) or Full Speed (12 Mbps).

  • Page 74: Usb Keyboard / Mouse Support

    Select “Enabled” if you plan to use a USB keyboard. The choices are “Enabled” and “Disabled”. Figure 2.8: Onboard Device 2.6.12 HD Audio Codec Allows you to enable or disable the High Definition Audio Controller. Configuration options: [Enabled] [Disabled] AIMB-564 User Manual...

  • Page 75: Figure 2.9 Super I/O Device

    Figure 2.9: Super I/O Device 2.6.13 Onboard FDC Controller When enabled, this field allows you to connect your floppy disk drives to the onboard floppy disk drive connector instead of a separate controller card. If you want to use a different controller card to connect the floppy disk drives, set this field to Disabled.

  • Page 76: Parallel Port Mode

    1 or DMA channel 3. Leave this field on the default setting. 2.6.20 PWRON After PWR-Fail Use this to set up the system after power failure. The “Off” setting keeps the system powered off after power failure, the “On” setting boots up the system after failure. AIMB-564 User Manual...

  • Page 77: Power Management Setup

    2.7 Power Management Setup The power management setup controls the single board computer's “green” features to save power. The following screen shows the manufac- turer’s defaults. Figure 2.10: Power management setup screen 2.7.1 ACPI Function The choices are: “Enabled” and “Disabled”. 2.7.2 ACPI Suspend Type This item allows you to set ACPI suspend type to S1/POS(Power On Sus-...

  • Page 78: Power Management

    When the system is in suspend mode, the video will turn off. The choices are “No” and “Yes”. 2.7.7 Suspend Type The choices are “Stop Grant” and “PwrOn Suspend”. 2.7.8 Suspend Mode Please refer to 3.7.5. 2.7.9 HDD Power Down Please refer to 3.7.5. AIMB-564 User Manual...

  • Page 79: Soft-Off By Pwr-Bttn

    2.7.10 Soft-Off by PWR-BTTN If you choose “Instant-Off”, then pushing the ATX soft power switch but- ton once will switch the system to “system off” power mode. You can choose “Delay 4 sec”. If you do, then pushing the button for more than 4 seconds will turn off the system, whereas pushing the button momentarily (for less than 4 seconds) will switch the system to “suspend”...

  • Page 80: Pnp/Pci Configuration

    Windows 95 or above. 2.8.4 PCI / VGA Palette Snoop This is set to “Disabled” by default. 2.8.5 Maximum Payload Size This allows you to set the maximum TLP payload size for PCIe devices. The options are [128 bytes]. AIMB-564 User Manual...

  • Page 81: Pc Health Status

    2.9 PC Health Status Figure 2.12: PC Health Status Screen 2.9.1 System Temperature This shows you the current temperature of system. 2.9.2 CPU FAN Speed This shows the current CPU FAN operating speed. 2.9.3 System FAN Speed This shows the current System FAN, including Power and Chassis fan, operating speed.

  • Page 82: Figure 2.13 Spread Spectrum Frequency/Voltage Con Trol Screen

    This is achieved by varying the frequency slightly so that the signal does not use any par- ticular frequency for more than a moment. The choices are “Disabled” and “Enabled”. AIMB-564 User Manual...

  • Page 83: Tpm Support

    2.11 TPM Support Figure 2.14: Security Chip Configuration The items in this menu allow you to set the TPM (Trusted Platform Mod- ule) features. Select an item and then press <Enabled> to display the con- figuration options. 2.11.1 TPM Support [Disabled] This item is not configurable.

  • Page 84: Figure 2.15 Security Chip Configuration

    Figure 2.15: Security Chip Configuration Figure 2.16: TPM POST Screen Caution! Once the data saved in the TPM security chip is cleared, it can never be restored. AIMB-564 User Manual...

  • Page 85: Password Setting

    2.12 Password Setting Follow these steps to change the password. Choose the “Set Password” option from the “Initial Setup Screen” menu and press <Enter>. The screen displays the following mes- sage: Please Enter Your Password Press <Enter>. If the CMOS is good and this option has been used to change the default password, the user is asked for the password stored in the CMOS.

  • Page 86: Save & Exit Setup

    CMOS memory of the chipset. The processor will check this every time you turn your system on and compare this to what it finds as it checks the system. This record is required for the sys- tem to operate. AIMB-564 User Manual...

  • Page 87: Exit Without Saving

    2.14 Exit Without Saving Selecting this option and pressing <Enter> lets you exit the setup program without recording any new values or changing old ones. Chapter 2 Product Information...
