7 Projection Distances
Screen
Diagonal Width
Size (in.) (m)
100 2.21
120 2.66
150 3.32
180 3.98
200 4.43
220 4.87
250 5.53
280 6.20
300 6.64
Screen
Diagonal Width
Size (in.) (in.)
100 87.2
120 104.6
150 130.7
180 156.9
200 174.3
220 191.7
250 217.9
280 244.0
300 261.5
7 Projection Distances
1.78:1 (16:9) Screen
T1 (1.37-1.66:1)
Height Min Max
(m) (m) (m)
1.25 3.03 3.73
1.49 3.65 4.48
1.87 4.58 5.62
2.24 5.52 6.76
2.49 6.14 7.52
2.74 6.75 8.28
3.11 7.68 9.41
3.49 8.60 10.56
3.74 9.22 11.32
T1 (1.37-1.66:1)
Height Min Max
(in.) (ft.) (ft.)
49.0 9.9 12.2
58.8 12.0 14.7
73.5 15.0 18.4
88.2 18.1 22.2
98.1 20.1 24.7
107.9 22.1 27.2
122.6 25.2 30.9
137.3 28.2 34.6
147.1 30.2 37.1
Projection Distance
T2 (1.75-2.48:1) T3 (2.54-3.90:1)
Min Max Min
(m) (m) (m)
3.92 5.22 5.76
4.72 6.38 6.91
5.93 8.24 8.63
7.13 9.96 10.36
7.94 11.07 11.51
8.74 12.18 12.66
9.96 13.84 14.39
11.15 15.50 16.12
11.94 16.60 17.27
Projection Distance
T2 (1.75-2.48:1) T3 (2.54-3.90:1)
Min Max Min
(ft.) (ft.) (ft.)
12.9 17.1 18.9
15.5 20.9 22.7
19.5 27.0 28.3
23.4 32.7 34.0
26.0 36.3 37.8
28.7 40.0 41.5
32.7 45.4 47.2
36.6 50.8 52.9
39.2 54.5 56.7
Vertical
Offset
(m)
Max
(m)
8.63 0.62
10.36 0.75
12.95 0.93
15.54 1.12
17.27 1.25
18.99 1.37
21.58 1.56
24.17 1.74
25.90 1.87
Vertical
Offset
(in.)
Max
(ft.)
28.3 24.5
34.0 29.4
42.5 36.8
51.0 44.1
56.6 49.0
62.3 53.9
70.8 61.3
79.3 68.6
85.0 73.5
SUPERLUMIS 41
User Guide
