DynamicBlack
This function improves the level of black and increases the depth and the detail of the
image especially in parts with low and medium brightness. DynamicBlack regulates
light based on the informative content of the image being projected. Available settings
are Off, Video and Movie. Off is recommended when using test pattern for
measurement or calibration purposes.
PureMotion
Activates the motion estimation/motion compensation function, which suppresses
motion judder. Settings available are Off, Low, Medium, or High. Default setting is
Low.


This menu section provides access to some advanced image settings. Adjustments not
available for a given input are not displayed in the menu. See
Table 4.4
Aspect
Color Management
Gamma Correction
Over scan
Position
Frequency
Phase
Y/C Delay
Signal Range
Lamp Power
Notes:
1. when RGB or AVI infoframe missing or incomplete
Aspect
This adjustment changes the dimensions and aspect ratio (relationship between width
and height) of the displayed image. There are six default aspects available and three
user aspects (with user-settable parameters). You can select a different aspect for
each source: the selected aspect ratio will be automatically applied the next time the
relative source is displayed. You can also select the required aspect ratio from the
remote control by repeatedly pressing
1-9. The following aspects are available:
•
Normal projects the image occupying the full height of the screen while
maintaining the aspect ratio of the input signal. When the input signal aspect
ratio is 4:3, black vertical bands are displayed on the right and left of the
picture.
•
Anamorphic correctly displays a 16:9 image with over scan.
4 Operation
RGBS
Video
YPrPb Graphics
● ●
● ●
● ●
● ●
● ●
●
●
●
● ●
or by pressing
Table 4.4 for details.
RGB
HDMI 1/2
● ●
● ●
● ●
●
●
●
●
1
●
● ●
and one of the number
