Basic Assembly
Color frame holder
Accessory holder door
Fresnel lens
W A R N I N G :
Basic Assembly
Figure-1 Source Four Fresnel fixture components.
Please note the following safety warnings before use:
Do not use this fixture with a damaged power lead. If the power lead
(cordset) is damaged, it must be replaced.
Do not mount the fixture on or near combustible surfaces.
Do not operate the fixture without a lens installed.
Always hang the fixture with the accessory door in the locked position.
Safety screen
(CE markets only)
Yoke
Field angle adjustment
knob
Lamp door
Lamp
Lamp holder base
1
