ETC Source Four User Manual page 12

Step 1: Release the accessory holder door by pressing in on the latches located on each side of
the door.
Step 2: Insert the color frame or accessory.
Step 3: Press down on the two accessory door latches to lock the door in place.
N o t e :
N o t e :
8
Latch
Figure-8 Accessory holder door releases.
Use only color frames or accessories with a 7.5 inch mounting flange.
The performance of saturated colors may be less than desirable in any theatrical
lighting fixture, especially when equipped with a 750w lamp. For best results,
always use high-quality color media rated for high-temperature use.
A variety of heat shield products is also available from many color media
manufacturers. Follow the manufacturer's instructions for the use of these
products.
Lift front to open
Latch
Accessory
slots
Source Four Fresnel User Manual
