I n s t a l l i n g a n d R e p l a c i n g t h e L a m p
A lamp must be installed before you use the fixture.
N o t e :
W A R N I N G :
Step 1: Disconnect power to the fixture before installing or replacing the lamp.
Step 2: On the bottom of the fixture, turn the latch on the lamp door one-quarter turn and then
open the door.
Step 3: Remove the lamp holder assembly by turning the knurled knob counterclockwise to
release the lamp socket assembly.
Lamp Information
Figure-2 Lamp door on bottom of the fixture.
Verify that the HPL lamp you intend to install is suitable for your facility's voltage;
115-, 120-, 230-, and 240-volt HPL lamps are available.
See HPL Lamp Table, page
reduces lamp life and can cause premature lamp failure.
Unplug the fixture and allow it to cool down before attempting to change the
lamp.
2. Operating HPL lamps above their rated voltage
Lamp door latch
Lamp door
3
