Performance Curves - ALLEN & HEATH XONE V6 User Manual

Channel Hi-Pass filter
response of the filter at its minimum (30Hz) and maximum
(600Hz) settings. The curve can be swept between these
positions.
Channel High-Pass filter Min/Max
20.00 Hz 100.00
XONE:V6 User Guide
This graph shows the
1000.00 10000.00 20000.00
Microphone EQ
the equaliser at maximum LF and HF boost and cut. The
shelves are tuned for vocal equalisation at 120Hz (LF) and
2.5kHz (HF). Maximum cut/boost is 15dB.
dBr
10.00
0.00
-10.00
-20.00
-30.00
-40.00
20.00 Hz 100.00
This graph shows the response of
Mic EQ
1000.00
dBr
20.00
15.00
10.00
5.00
0.00
-5.00
-10.00
-15.00
-20.00
10000.00 20000.00
39
