XLT Ovens XLT Installation & Operation Manual page 46

46
Front of Hood Canopy
(90 [2286])
69 1/2
±1/8
[1765 ]
±3.2
Finished Floor
NOTE: All dimensions in inches [mm] unless otherwise noted.
Single Stack
Double Stack
Triple Stack
Hood Dimensions
Hood Weight (Does not include ovens)
AVI AVI AVI
1832 2440 3240
560.39 644.84 708.73
[254] [292] [321]
513.78 576.72 640.25
[233] [262] [290]
594.64 593.48 657.82
[270] [269] [298]
NOTE: All weights in pounds [kg].
Switches to be on
Front of the Hood
AVI AVI AVI
3255 3270 3855
757.05 790.12 812.03
[343] [358] [368]
681.29 704.08 728.01
[309] [319] [330]
698.99 709.52 840.39
[317] [322] [381]
AVI
3870
845.32
[383]
750.23
[340]
754.55
[342]
